Panasonic Lumix S1H Handbook

Measurement of Luminance Level : Zebra Pattern
80
7. Video Shooting Assist Functions
Select [ BASE/RANGE ]
3
Set the reference brightness and the range to
be indicated with a striped pattern.
Usual Setting V-Log
Base Level
0 to 109 % -8 to 6.3 stop
Range
±
1 to
±
10 %
±
0.2 to
±
1.0 stop
• Calculated as 0 Stop=42% (IRE)
1
2
[ ] > [ ] > [ Zebra Pattern ] > [ SET ]
A function can be assigned to
the Fn button for quick access.
[ ] > [ ] > [ Fn Button Set ]
[ 2 ] > [ ] > [ Zebra Pattern ]

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
