Use of the bundled cable holder prevents detachment of the cable and damage to the terminals.
Put the camera on a stable surface to perform this task.
37
Attaching the Cable Holder 1 / 2
While pushing A, slide the clamp portion
B of the cable holder to remove it.
Loosely mount the cable holder to the mount
on the camera, and then rotate the screws in
the direction of the arrows to secure the
cable holder D.
2
3
1
4
Open the door of the terminal section and
slide the door into the part marked
C.
Fit the USB connection cable (C–C or A–C)
E and HDMI cable F to the clamp.
Note : Use a High-Speed HDMI cable
(Type A-Type A plug, up to 1.5 m (4.9 feet))
with the HDMI logo. Cables that do not comply
with the HDMI standards will not work.
3. HDMI Output and TC IN/OUT
To Next Page
