Panasonic Lumix S1H Handbook

38
Attaching the Cable Holder 2 / 2
6
5
Slide the clamp portion G to attach it to
the cable holder.
Connect the USB connection cable (C–C
or A–C) to the USB port
H.
Connect the HDMI cable to the [HDMI]
socket
I.
J Leave some slack so that this section
has a length of at least 10 cm (0.33 feet).
7
Removing the Cable Holder
To remove the cable holder, follow the steps
for attaching it in the reverse order.
8
3. HDMI Output and TC IN/OUT

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
