Panasonic Lumix S1H Handbook

Mic Input
Plugin Power
Power is supplied to an
external mic by the camera.
Mic Input
Power is not supplied to an
external mic by the camera.
Line Input
When connecting an external
audio device for line output.
Φ 3.5mm Stereo Mini Jack
The audio input from the external microphone
or XLR Microphone Adaptor DMW-XLR1* is
muted.
• When recording the audio separately.
• For live streaming studio commentary.
Input Settings Switching
When Muting the Audio Input
The settings can be switched depending on the need for power supply.
They also support Line Input.
44
4. Audio Settings
Mic Input
* Sold separately.
[ ] > [ ] > [ Mute Sound Input ]
[ ] > [ ] > [ Mic Socket ]

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
