Panasonic Lumix S1H

Input-Output Terminal / Extended Capability 2 / 2
8
Flash Synchro Socket
Use the flash with a synchronization voltage of 250V or less.
TC IN/OUT Socket
Use the bundled BNC conversion cable.
Input: 1.0V to 4.0V [p-p], 10 kΩ, Output: 2.0V ± 0.5 V [p-p], low impedance
9
Screw Hole for Function Expansion
Use the screw hole for attaching the lens or lens mount adaptor
that can be secured with a screw.
10
Focus Distance Reference Mark
Positioned coaxially with the strap eyelet in consideration of the attachment of
a tape measure to the strap eyelet.
11 Tripod Mount
12 Pinhole for Anti-rotation Pin of Video Tripod Mount
8
Main Parts
6
1. Main Parts and Displays
9
10
11 12
Note : If you attempt to attach a tripod with a screw length of 5.5mm (0.22 inch) or
more, you may not be able to securely fix it in place or it may damage the camera.
Fn1 Button
Preview Button / Fn2 Button
