Panasonic Lumix S1H

Power Supply DC Coupler / AC Adaptor (Sold Separately)
61
6. Power Supply and Recording Media
The AC Adaptor DMW-AC10 to the DC Coupler
DMW-DCC16 also allow you to supply power to
the camera.
AC Adaptor DMW-AC10
DC Coupler DMW-DCC16
Separately sold parts must be purchased.
* The AC Adaptor DMW-AC10 and the DC coupler DMW-
DCC16 cannot be used independently of one another.
Open the battery door.
1
Insert the DC Coupler paying
attention to its direction.
2
Open the DC Coupler cover
and then thread the cable.
3
Close the battery door firmly.
4
Connect the AC Adaptor to
the DC Coupler.
5
When the DC Coupler is being mounted, the DC Coupler cover opens, so the structure ceases to be
dust and splash-resistant. Do not allow sand, dust and water droplets to adhere to or enter the camera.
After use, confirm that no foreign objects are adhering to the DC Coupler cover, then firmly close the cover.
