Panasonic MBDLN25SE - Encoder Connector X6 Pinout

No. SX-DSV03015 - 20 -
Motor Business Unit, Panasonic Corporation
6-4 Encoder connector X6
Name
Connector
pin No.
Description
Encoder power supply output
1
E5V
2
E0V (*Note 1)
－
3
Do not connect.
4
Do not connect.
Encoder signal I/O
(serial signal)
5
PS
6
/PS
Frame ground
shell
FG
*Note 1) The E0V of the encoder power supply output is connected with the control circuit ground of the connector X4 .
