Panasonic NA-F1011T

2
CONTENTS
Usage: For repairs and change of spare part only for washing machine type
Panasonic Model NA-F80B1/NA-F80T1/NA-F80H1/NA-F90T1/NA-F90H1/
NA-F1011T
Instruction
for Usage: The work repair and changing of space part should be operated by a skilled
technician from the distribution agents, or Panasonic’s standard service center.
Warning: Switch off electrical power before commencing work to avoid a potential short
circuit or injury.
1. SPECIFICATIONS .........................................................................................3
2. FEATURES AND TECHNICAL INFORMATION .......................................... 4-5
3. INSTALLATION ......................................................................................... 6-7
4. OPERATIONS PANEL ............................................................................... 8-9
5. WIRING DIAGRAM .....................................................................................10
6. TABLE OF ERRORS ...................................................................................11
7. TROUBLESHOOTING .......................................................................... 12-14
8. DISASSEMBLY INSTRUCTION ...................................................................15
9. LOCATION OF PARTS AND REPLACEMENT PARTS ........................... 16-29
Page
