9.6.1 Replacement of Parts List - C
9. LOCATION OF PARTS AND REPLACEMENT PARTS
REPLACEMENT PARTS LIST
Important safety notice :
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer’s specified part.
Parts List - C of NA-F80B1
Ref.
No.
Part Name Part No. Safety
Countries
Remark
Thai Viet Mal Sin-Lo India Sin-Ex
C1 Outer Tub Cover AXW32246CH10 1 1 1 1 1 1
C2 O-Ring AXW02577BK00 1 1 1 1 1 1
C3 Pulsator Unit AXW05016ZR1P 1 1 1 1 1 1
C4 Shaft Bushing AXW05046ZR00 1 1 1 1 1 1
C5 Spinner Shaft Flange Nut AXW15176RU10 1 1 1 1 1 1
C6 Spinner Flange Washer B AXW151980200 1 1 1 1 1 1
111111
C7 Filter Unit AXW022A7FX1P
C8a Suspension Unit (R-RL) AXW034U7BK10 2 2 2 2 2 2 Rear : Right & Left
C8b Suspension Unit (F-R) AXW034U7BK60 1 1 1 1 1 1 Front : Right
C8c Suspension Unit (F-L) AXW034U7BKB0 1 1 1 1 1 1 Front : Left
C9 Outer Tub A AXW12016CG30 1 1 1 1 1 1
C9a Outer Tub B AXW12027BK10 1 1 1 1 1 1
C10 Motor Washer A AXW04207BK00 2 2 2 2 2 2
C11 Motor AXW040157626
S
111111
C12 Motor Washer B AXW04217BK10 2 2 2 2 2 2
C13 Motor Pulley AXW04116XB00 1 1 1 1 1 1
C14 V-Belt AXW041219860 1 1 1 1 1 1
C15 Spinner Plate B AXW32327BL00 1 1 1 1 1 1
C16 Valve Unit AXW009D6ZR00 1 1 1 1 1 1
C17 Geared Motor AXW348202516
S
111111
C18 Lead Wire Unit AXW014B6UP00
S
111111
C19 Over Flow Hose B AXW02345TW0M 1 1 1 1 1 1
C20 Earth Wire Unit (Internal) AXW003F6UP00
S
111111
C21 Mecha-Case Unit AXW020A6UA60 1 1 1 1 1 1
C22 Tub Unit AXW002A7FZ00 1 1 1 1 1 1
C23 Flexible Hose A Unit AXW002D6RU00 1 1 1 1 1 1
C24 Hose Band AXW02457EC00 1 1 1 1 1 1
Screws
Ref.
No.
Part Name Part No. Safety
Countries
Remark
Thai Viet Mal Sin-Lo India Sin-Ex
Special Tapping Screw XTWAXW529 8 8 8 8 8 8 Tub A~Tub D
6 6 6 6 6 6 Spinner Shaft Flange
Pan Head Tapping Screw XTN4+8HFJ 1 1 1 1 1 1 Earth U~Body A
Special Small Screw XSSAXW682 1 1 1 1 1 1 Pulsator Unit
111111Motor Pulley
Special Bolt XVGAXW703J-U
XVGAXW839J 2 2 2 2 2 2 Motor
XVGAXW812J 4 4 4 4 4 4 Mecha-Case~Outer Tub B
444444Outer Tub CoverXTWAXW435
XTWAXW682J 2 2 2 2 2 2 Spinner Plate B
Special Tapping Screw XTWAXW6517J 6 6 6 6 6 6 Outer Tub A,B
XTWAXW6518J 3 3 3 3 3 3 Geared Motor (Clutch)
XTWAXW531 2 2 2 2 2 2 Outer Tub A, B ~ Center
222222Valve UnitXTWAXW6517J
