Panasonic NA-F115A1

ECONAVI lamp
(NA-F135X1 / NA-F115X1)
•
Operation panel
of the NA-F135X1
Power Off/On
Air Dry
Start/Pause
Program selection
Child Lock lamp
Change process
settings
Change the combination of wash,
rinse and spin processes, and the
time length or number of times for
individual processes.
Flashing(inprogress)
Lighted
● After starting operation, you
can change settings only during
wash process by pressing
“Start/Pause”.
Preset
Set the time to finish washing (in
hours). (
lights.)
e.g.)8hourslater
● Setting range: 2 - 24 hours later,
in one-hour increments. (3 - 24
hours later for the Power wash
+ Soak program)
● Not available for the following
programs:
Delicate, Fragrance, Blanket,
Tub Hygiene, Air Dry
NOTE
● In case of a power failure
during operation, operation will
resume from the point where it
was stopped when the power
is recovered (Auto Restart).
● The power turns off
automatically if you do not
press “Start/Pause” within
10 minutes after power-on.
Change water
amount
During the wash
process, press “Water
Level” to change the
water amount.
● Some water amounts
cannot be selected
depending on the
program.
● When the remaining
time is displayed,
press “Water Level”
to check the water
amount.
Water level/water amounts
Level
High
10-8
Mid
7-5
Low
4-2
Extra
Low
1
Model
Detergent*
Water
amount (L)
93 86 81 73 66 58 52 46 38 33
NA-
F135X1
NA-
F135A1
90 86 81 73 66 58 52 46 38 33
NA-
F125A1
86 81 73 66 58 54 52 46 38 33
NA-
F115X1
NA-
F115A1
* : 1 scoop of detergent
● Each water level, except “Extra Low”, has
three water amount options that can be
switched while the level is lit by pressing
“Water Level”. (Example: For NA-F135X1,
“High” has 93 L, 86 L and 81 L options.)
Water amount/
remaining time
After starting operation, indicates
the water amount according to
the amount of laundry.
After approx. 5 seconds, indicates
the approximate remaining time
(min).
6. OPERATION PANEL
- 9 -
