6.1.7. HOW TO REMOVE A JAMMED TAPE
Remove a jammed tape in Electrical Method as follows:
1. Remove the Cabinet Parts. Then, remove the 3 Screws and the
Mechanism Base Unit from the Mechanism Chassis Ass'y as
shown. Refer to "CABINET SECTION" & "MECHANISM SECTION"
in DISASSEMBLY/ASSEMBLY PROCEDURES.
2. Apply +3 V DC Power Supply to the Portion "a" and "b" on the
Mechanism F.P.C. Unit.
Note:
DO NOT let eject the Garage Unit with grasping the Cassette
Cover. If the Garage Unit is in the up position, a cassette tape may
be damaged.
17
