Panasonic NV-DS30A - Integrated Circuits

Ref. No. Part No. Part Name & Description Remarks
E10 LSEP8165P1 MAIN C.B.A. ( A,B,C,D ) E.S.D.
E10 LSEP8165Q1 MAIN C.B.A. ( E,F,G,H ) E.S.D.
E10 LSEP8165R1 MAIN C.B.A. ( I,J,K,L ) E.S.D.
E10 LSEP8165S1 MAIN C.B.A. ( M,N,O ) E.S.D.
E20 LSEP8183P1 REAR C.B.A.
( A,B,C,D,E,F,G,H,I,J,K,L )
E.S.D. RTL
E20 LSEP8183Q1 REAR C.B.A. ( M,N,O ) RTL
E30 LSXM0024 MICROPHONE C.B.A. RTL
E40 LSEP8193A1 FRONT C.B.A. RTL
E50 LSEP8169B1 ELECTRONIC VIEWFINDER BACK LIGHT C.B.A. RTL *NOTE
E60 LSEP8188B1 LIQUID CRYSTAL DISPLAY C.B.A. RTL
E70 LSEQ0639 CCD C.B.A. NR
E80 LSEP8177C1 TOP OPERATION C.B.A. NR
13.3.1. REAR C.B.A.
INTEGRATED CIRCUITS
Ref. No. Part No. Part Name & Description Remarks
IC6701 C0ZBZ0000275 IC, LINEAR ( A,B,C,D,E,F,G,H,I,J,K,L )
IC6701 C0ZBZ0000540 IC, LINEAR ( A,B,C,D,E,F,G,H,I,J,K,L )
IC6701 C1ZBZ0001923 IC, LINEAR ( A,B,C,D,E,F,G,H,I,J,K,L )
IC6702 S814A33AMC-B IC, CMOS STANDARD LOGIC ( A,B,C,D,E,F,G,H,I,J,K,L ) E.S.D.
DIODES
Ref. No. Part No. Part Name & Description Remarks
D1201 RD12S-T1B DIODE ZENER CHIP 12V
D1202 RD12S-T1B DIODE ZENER CHIP 12V
D6701 MA2S728008 DIODE SI CHIP ( A,B,C,D,E,F,G,H,I,J,K,L )
D6701 B0JCDD000002 DIODE SI CHIP ( A,B,C,D,E,F,G,H,I,J,K,L )
D6701 MA2S72800L DIODE SI CHIP ( A,B,C,D,E,F,G,H,I,J,K,L )
D7001 B0BD6R800009 DIODE ZENER CHIP 6.8V
D7002 B0BD6R800009 DIODE ZENER CHIP 6.8V
D7003 B0BD6R800009 DIODE ZENER CHIP 6.8V
D7004 RD6.2S DIODE ZENER CHIP 6.2V
D7005 B0BD6R800009 DIODE ZENER CHIP 6.8V
D7006 RD6.2S DIODE ZENER CHIP 6.2V
