Ref. No. Part No. Part Name & Description Remarks
R6703 LSRJ0002 VARIABLE RESISTOR ( A,B,C,D,E,F,G,H,I,J,K,L )
R6704 LSRJ0002 VARIABLE RESISTOR ( A,B,C,D,E,F,G,H,I,J,K,L )
R6706 ERJ3GEY0R00V MGF CHIP 1/16W 0 ( M,N,O )
R6707 ERJ3GEY0R00V MGF CHIP 1/16W 0 ( M,N,O )
R7001 ERJ3GEYJ331V MGF CHIP 1/16W 330
R7003 ERJ3GEYJ561V MGF CHIP 1/16W 560
CAPACITORS
Ref. No. Part No. Part Name & Description Remarks
C1201 ECJ1VF1H103Z C CHIP 50V 0.01UF
C1202 ECJ1VF1H103Z C CHIP 50V 0.01UF
C6701 F1J1A1050002 C CHIP 10V 1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C6702 ECJ1VB1C104K C CHIP 16V 0.1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C6703 ECJ1VB1C104K C CHIP 16V 0.1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C6704 ECJ1VB1C104K C CHIP 16V 0.1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C6705 ECJ1VB1C104K C CHIP 16V 0.1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C6706 ECJ2YB1A105K C CHIP 10V 1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C6708 ECJ2YB1A105K C CHIP 10V 1UF ( A,B,C,D,E,F,G,H,I,J,K,L )
C7001 ECJ1VB1H472K C CHIP 50V 4700PF
C7002 ECJ1VB1H472K C CHIP 50V 4700PF
FILTERS
Ref. No. Part No. Part Name & Description Remarks
FL1201 J0MAB0000062 FILTER
COILS
Ref. No. Part No. Part Name & Description Remarks
L6701 ERJ3GEYJ821V MGF CHIP 1/16W 820 ( A,B,C,D,E,F,G,H,I,J,K,L )
L6702 ERJ3GEYJ821V MGF CHIP 1/16W 820 ( A,B,C,D,E,F,G,H,I,J,K,L )
L6703 ERJ3GEY0R00V MGF CHIP 1/16W 0 ( A,B,C,D,E,F,G,H,I,J,K,L )
L6704 ERJ3GEY0R00V MGF CHIP 1/16W 0 ( M,N,O )
L6705 ERJ3GEY0R00V MGF CHIP 1/16W 0 ( M,N,O )
L6706 ERJ3GEY0R00V MGF CHIP 1/16W 0 ( M,N,O )
L6707 VLQ0807K100 COIL CHIP 10UH ( A,B,C,D,E,F,G,H,I,J,K,L )
L7001 J0JBC0000027 FERRITE BEAD CHIP
L7002 J0JBC0000027 FERRITE BEAD CHIP
L7003 J0JBC0000027 FERRITE BEAD CHIP
L7004 J0JBC0000027 FERRITE BEAD CHIP
L7005 J0JBC0000027 FERRITE BEAD CHIP
FUSE & PROTECTOR
Ref. No. Part No. Part Name & Description Remarks
IP1201 K5H2022A0008 CIRCUIT PROTECTOR CHIP 32V 2A
IP1202 K5H1022A0008 CIRCUIT PROTECTOR CHIP 32V 1A
SWITCHES
Ref. No. Part No. Part Name & Description Remarks
SW1201 ESE22MH4 SWITCH PUSH
