Panasonic NV-DS30A - Page 81

Ref. No. Part No. Part Name & Description Remarks
283 LSLL0028 LAMP
2
284 LSEK0409 LAMP SOCKET UNIT 2
285 LSGB0031 MULTI MEDIA CARD BADGE ( M,N,O ) 1
286 LSEU03B55UU DEW CABLE W/OUT PLUG,1V 6
287 LSMT0075 MASK CUSHION,URETHANE 4 *NOTE
288 LSMF0214 SHEET,NYLON-RAYON 4 *NOTE
289 LSMT0370 CUSHION,RUBBER 4 *NOTE
290 LSMT0076 CUSHION,RUBBER 2
301 LSYK0837 FRONT CASE UNIT,ABS RESIN 2
302 LSYK0839 FRONT COVER UNIT 5
303 LSYK0861 TOP/ELECTRONIC VIEWFINDER UNIT ( A,B,C,D ) 4
303 LSYK0862 TOP/ELECTRONIC VIEWFINDER UNIT ( E,F,G,H,I,J,K,L ) 4
303 LSYK0863 TOP/ELECTRONIC VIEWFINDER UNIT ( M,N,O ) 4
304 LSYK0845 CASSETTE COVER UNIT 1
305 LSYK0843 SIDE CASE R UNIT,ABS RESIN 5
402 XQN2+BJ4FXK SCREW,STEEL 4,5
403 XQN2+BF4FXK SCREW,STEEL 5
404 XQN2+BJ5FXK SCREW,STEEL 1,2,4,5
407 XQN2+BF4FN SCREW,STEEL 4 *NOTE
413 LSHD0051 SCREW,STEEL 6
416 XQN2+BJ3FXK SCREW,STEEL 4
422 XQN16+CJ5FY SCREW,STEEL 3
429 XQN14+B35 SCREW,STEEL 6
432 XQN14+B2 SCREW,STEEL 6
471 XQN14+B35FNK SCREW,STEEL 6
473 VMX2026 CUT WASHER,STEEL 6
475 VMX2750 CUT WASHER,STEEL 6
477 VMX2028 CUT WASHER,STEEL 6
478 XQN14+B12FN SCREW,STEEL 6
503 LSHD0073 SCREW,STEEL 6
504 XQN2+B35 SCREW,STEEL 6
507 XQN14+BJ4 SCREW,STEEL 3
509 XQN2+BF8FN SCREW,STEEL 5
510 XQN2+BF5FXK SCREW,STEEL 1
701 LSEK0447 ELECTORIC CONDENSER MICROPHONE UNIT 4 *NOTE
703 LSMG0111 MICROPHONE DAMPER 4 *NOTE
705 LSJW0033 FLEXIBLE FLAT CABLE W/OUT PLUG,4.8V 4 *NOTE
721 VMZW0660 INSULATION SHEET,PLASTIC 5
731 LSSB0004 BATTERY 1
735 LSEP8172A1 SD HOLDER UNIT NR ( M,N,O ) 1
E10 LSEP8165P1 MAIN C.B.A. ( A,B,C,D ) 1
E10 LSEP8165Q1 MAIN C.B.A. ( E,F,G,H ) 1
E10 LSEP8165R1 MAIN C.B.A. ( I,J,K,L ) 1
E10 LSEP8165S1 MAIN C.B.A. ( M,N,O ) 1
E20 LSEP8183P1 REAR C.B.A. ( A,B,C,D,E,F,G,H,I,J,K,L ) 1 RTL
E20 LSEP8183Q1 REAR C.B.A. ( M,N,O ) 1 RTL
E30 LSXM0024 MICROPHONE C.B.A. 4 RTL
E40 LSEP8193A1 FRONT C.B.A. 2 RTL
E50 LSEP8169B1 ELECTRONIC VIEWFINDER BACK LIGHT C.B.A. 4 RTL *NOTE
E60 LSEP8188B1 LIQUID CRYSTAL DISPLAY C.B.A. 5 RTL
E70 LSEQ0639 CCD C.B.A. NR 3
E80 LSEP8177C1 TOP OPERATION C.B.A. NR 4
81
