Panasonic NV-DS30A - Page 92

Ref. No. Part No. Part Name & Description Remarks
C8001 ECJ2YB1C474K C CHIP 16V 0.47UF
C8002 ECUV0J105KBV C CHIP 6.3V 1UF
C8003 ECUV0J105KBV C CHIP 6.3V 1UF
C8004 ECUV0J105KBV C CHIP 6.3V 1UF
C8005 F3F0J226A001 ELECTROLYTIC CHIP 6.3V 22UF
C8006 ECUE1H103KBV C CHIP 50V 0.01UF
C8007 F1K1C105A023 C CHIP 16V 1UF
C8008 ECJ1VB1C104K C CHIP 16V 0.1UF
C8009 ECJ2YF1C225Z C CHIP 16V 2.2UF
C8010 ECST0JY106 TANTALUM CHIP 6.3V 10UF
C8011 ECJ2YF1C225Z C CHIP 16V 2.2UF
C8012 ECJ2YF1C225Z C CHIP 16V 2.2UF
C8013 ECJ1VB1H152K C CHIP 50V 0.0015UF
C8014 ECJ2YB0J225K C CHIP 6.3V 2.2UF
C8015 ECJ2YF1C225Z C CHIP 16V 2.2UF
C8016 F1K1C2250005 C CHIP 16V 2.2UF
C8017 ECJ2YF1C225Z C CHIP 16V 2.2UF
C8019 ECJ1VB1C104K C CHIP 16V 0.1UF
C8021 ECJ1VC1H471J C CHIP 50V 470PF
C8022 ECJ1VC1H471J C CHIP 50V 470PF
C8023 ECJ1VC1H471J C CHIP 50V 470PF
C8107 ECUV1A106KBP C CHIP 10V 10UF
C8108 ECHU1H333JB5 POLYESTER CHIP 50V 0.033UF
C8109 LSCUCAD150J C CHIP 2KV 15PF
C8110 LSCUCAD220J C CHIP 2KV 22PF
C8113 ECJ1VB1C104K C CHIP 16V 0.1UF
C8114 ECUV0J105KBV C CHIP 6.3V 1UF
C8115 ECST0JY106 TANTALUM CHIP 6.3V 10UF
C8116 ECJ1VF1C104Z C CHIP 16V 0.1UF
C8117 F1J1C1050011 C CHIP 16V 1UF
C8118 ECJ1VF1C104Z C CHIP 16V 0.1UF
COILS
Ref. No. Part No. Part Name & Description Remarks
L8001 G1C150J00005 COIL CHIP 15UH
L8002 G1C150J00005 COIL CHIP 15UH
L8003 G1C150J00005 COIL CHIP 15UH
L8004 ERJ6GEY0R00V MGF CHIP 1/10W 0
L8005 G1C150J00005 COIL CHIP 15UH
L8103 G1C680M00005 CHOKE COIL
L8104 G1A100ZA0002 CHOKE COIL 10UH
FPC CONNECTOR
Ref. No. Part No. Part Name & Description Remarks
FP8001 K1MN25B00037 CONNECTOR 25P
FP8002 K1MN24B00077 CONNECTOR 24P
FUSE & PROTECTOR
Ref. No. Part No. Part Name & Description Remarks
PR8101 K5H1022A0008 CIRCUIT PROTECTOR CHIP 32V 1A
92
