13
3.3 CU-2Z50TBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 2.0kW + 2.5kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
Cooling Operation
Capacity
kW 5.0 (1.5 ~ 5.4)
BTU/h 17100 (5120 ~ 18400)
Electrical
Data
Running Current A 5.35
Power Input kW 1.18 (0.25 ~ 1.49)
EER W/W 4.24 (6.00 ~ 3.62)
Annual Energy Consumption (A.E.C) kWh 590
Annual Consumption kWh 206
Noise
Sound Pressure Level dB-A (H/L) 50 / -
Sound Power Level dB (H/L) 65 / -
Heating Operation
Capacity
kW 5.6 (1.1 ~ 7.2)
BTU/h 19100 (3750 ~ 24600)
Electrical
Data
Running Current A 5.50
Power Input kW 1.21 (0.21 ~ 1.80)
COP W/W 4.63 (5.24 ~ 4.00)
Annual Consumption kWh 1278
Noise
Sound Pressure Level dB-A (H/L) 52 / -
Sound Power Level dB (H/L) 67 / -
Maximum Current A 11.5
Maximum Input Power W 2.62k
Starting Current A 5.5
Dimension
Height mm 619
Width mm 824 (+70)
Depth mm 299
Net Weight kg 39
Pipe Length Range (1 room) m 3 ~ 20
Maximum Pipe Length (Total Room) m 30
Piping
Standard Length m 5
Height Difference m 10
Add. Gas Amount g/m 15
Pipe Length for Add. Gas m 20
Refrigerant Pipe Diameter
Liquid Side mm (inch) 6.35 (1/4)
Gas Side mm (inch) 9.52 (3/8)
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Rated Output W 900
Air Circulation
Type Propeller Fan
Motor Type DC Motor (8-poles)
Rated Output W 40
Fan Speed High (Cooling / Heating) RPM 900 / 1000
Heat Exchanger
Type Plate fin configuration forced draft type
Tube Material Copper
Fin Material Aluminum (Pre Coat)
Row / Stage 2 / 18
FPI 17
