9
3. Specifications
3.1 CU-2Z35TBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 2.0kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
Cooling Operation
Capacity
kW 3.5 (1.50 ~ 4.50)
BTU/h 11900 (5120 ~ 15300)
Electrical
Data
Running Current A 3.35
Power Input kW 0.72 (0.25 ~ 1.10)
EER W/W 4.86 (6.00 ~ 4.09)
Annual Energy Consumption (AEC) kWh 360
Annual Consumption kWh 144
Noise
Sound Pressure Level dB-A (H/L) 48 / -
Sound Power Level dB (H/L) 63 / -
Heating Operation
Capacity
kW 4.20 (1.1 ~ 5.60)
BTU/h 14300 (3750 ~ 19100)
Electrical
Data
Running Current A 4.0
Power Input kW 0.86 (0.21 ~ 1.34)
COP W/W 4.88 (5.24 ~ 4.18)
Annual Consumption kWh 974
Noise
Sound Pressure Level dB-A (H/L) 50 / -
Sound Power Level dB (H/L) 65 / -
Maximum Current A 10.5
Maximum Input Power W 2.39k
Starting Current A 4.00
Dimension
Height mm 619
Width mm 824 (+70)
Depth mm 299
Net Weight kg 39
Pipe Length Range (1 room) m 3 ~ 20
Maximum Pipe Length (Total Room) m 30
Piping
Standard Length m 5
Height Difference m 10
Add. Gas Amount g/m 15
Pipe Length for Add. Gas m 20
Refrigerant Pipe Diameter
Liquid Side mm (inch) 6.35 (1/4)
Gas Side mm (inch) 9.52 (3/8)
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Rated Output W 900
Fan Motor
Type Propeller Fan
Motor Type DC Motor (8-poles)
Rated Output W 40
Fan Speed High (Cooling / Heating) RPM 700 / 930
