Specications
ENGLISH -
73
Appendix
This is an average value. It may differ depending on individual product.*4 :
Measurement, measuring conditions and method of notation all comply with ISO21118 international *5 :
standards.
The part numbers of accessories and separately sold components are subject to change without notice.
z
Model No.
PT-CW330EA PT-CX300EA PT-CW240EA
Terminals
COMPUTER 1
IN/
COMPUTER 2
IN
2 set, high-density D-Sub 15p (female)
[RGB signal]
0.7 V [p-p] 75 Ω (When G-SYNC: 1.0 V [p-p] 75 Ω
HD/SYNC TTL high impedance, automatic positive/negative polarity compatible
VD TTL high impedance, automatic positive/negative polarity compatible
SYNC/HD and VD are not compliant with 3 value composite SYNC
[YP
B
P
R
signal]
Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
MONITOR OUT
1 set, high-density D-Sub 15p (female)
[RGB signal]
0.7 V [p-p] 75 Ω (When G-SYNC: 1.0 V [p-p] 75 Ω
HD/SYNC TTL high impedance
VD TTL high impedance
[YP
B
P
R
signal]
Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
VIDEO
1 (Pin jack 1.0 V [p-p] 75 Ω)
S-VIDEO
1 Mini DIN 4 pin, Y 1.0 V [p-p], C 0.286 V [p-p] 75 Ω
HDMI
1 (HDMI 19 pin, HDCP and Deep color compatible)
AUDIO
2 (M3 stereo mini jack, 0.5 V [rms], input impedance 22 kΩ and more)
2 (Pin jack x 2 (L-R), 0.5 V [rms], input impedance 22 kΩ and more)
VARIABLE
AUDIO OUT
1 (M3 stereo mini jack, stereo monitor output compatible,
0 V [rms] to 2.0 V [rms] valuable, output impedance 2.2 kΩ and less)
SERIAL IN
1 (D-sub 9 pin, RS-232C compliant, for computer control use
LAN
1 (For RJ-45 network connection: PJLink (class 1) compatible)
MINI USB
1 (For upgrading rmware)
Power cable length
3 m (118.1 ")
Cabinet
Molded plastic
Dimensions
Width: 357 mm (14.06")
Height: 250.4 mm (9.86") (when adjustable feet shortened)
Depth: 367 mm (14.45")
Weight
Approx.7.7 k
g
(16.98 lbs.) *
4
Approx.7.5 k
g
(16.53 lbs.) *
4
Noise level
*
5
When set to [Normal] in [Lamp power mode]: 37 dB
When set to [ECO] in [Lamp power mode]: 33 dB
Operating environment
Operating environment temperature:
5 °C to 40 °C (For 0 - 2 500 ft), (Elevation: below approx. 750 m);
5 °C to 35 °C (For 2 500 - 5 000 ft), (Elevation: approx. 750 m - approx.1 500 m);
5 °C to 30 °C (For 5 000 - 10 000 ft), (Elevation: approx. 1 500 m - approx.3 000 m);
Operating environment humidity: 20 % to 80 % (no condensation)
Remote
control
Power supply
DC 3 V (Lithium coin battery)
Operating
range
Approx. 8 m (26.25 ft) (when operated directly in front of signal receiver)
Weight
23.0
g
(0.811 ozs.) (including battery)
Dimensions
Width : 40.6 mm (1.60"), Length : 86.5 mm (3.41"), Height : 7.2 mm (0.28")
