Panasonic PT-DW730E - Page 105

Specications
ENGLISH - 105
Appendix
Model No. PT-DW730E PT-DW730EL PT-DX800E PT-DX800EL
Terminals
RGB2 IN
1 set, high-density D-Sub 15 p (female)
[RGB SIGNAL] 0.7 V [p-p] 75
Ω
(SYNC ON GREEN: 1.0 V [p-p] 75
Ω
)
SYNC/HD, TTL high impedance, automatic positive/negative polarity
compatible
VD, TTL high impedance, automatic positive/negative polarity compatible
[YP
B
P
R
signal] Y:1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75
Ω
VIDEO IN 1
set, BNC 1.0 V [p-p] 75
Ω
S-VIDEO IN 1 set, Mini DIN 4 p Y 1.0 V [p-p], C 0.286 V [p-p] 75
Ω
S1 signal compliant
SERIAL IN/OUT D-Sub 9 p, each set, RS-232C compatible, for computer control
REMOTE1 IN/
OUT
M3 stereo mini jack, for each remote control (wired) / projector connection control
REMOTE2 IN/
OUT
1 set, D-Sub 9 p (female), for external control (contact control)
DVI-D IN 1 set, DVI-D 24 p, single
link, DVI1.0 compatible, HDCP
compliant
LAN 1 set, RJ-45 for network connection, PJLink compliant, 10Base-T/100Base-TX
Power cable length 3.0 m (118-1/8")
Outer case Molded plastic
Dimensions
Width: 498 mm (19-19/32")
Height: 175 mm (6-7/8")
(feet at a minimum)
Depth: 466 mm (18-11/32")
(including the supplied
standard zoom lens)
Width: 498 mm (19-19/32")
Height: 175 mm (6-7/8")
(feet at a minimum)
Depth: 423 mm
(16-21/32")
W
idth: 498 mm (19-19/32")
Height: 175 mm (6-7/8")
(feet at a minimum)
Depth: 466 mm (18-11/32")
(including the supplied
standard zoom lens)
Width: 498 mm (19-19/32")
Height: 175 mm (6-7/8")
(feet at a minimum)
Depth: 423 mm (16-21/32")
Weight
Approx. 16.3 kg (35.9 lbs.)
*3
(including the supplied
standard zoom lens)
Approx 15.4 kg (34 lbs.)
*3
Approx. 16.3 kg (35.9 lbs.)
*3
(including the supplied
sta
ndard zoom lens)
Approx 15.4 kg (34 lbs.)
*3
Operating environment
Operating environment temperature
*4
: 0
°
C (32
°
F) to 45
°
C (113
°
F)
Operating environment humidity: 20% to 80% (no condensation)
Remote
control
Power supply DC 3 V (AA/R6 battery x 2)
Operating range Approx. 30 m (98'5") (when operated directly in front of signal receiver)
Weight 134 g (4.7 ozs.) (including batteries)
Dimensions Width: 51 mm (2"), H
eight: 176 mm (6-15/16"), Depth: 22.7 mm (29/32")
*
1: The supplied standard zoom lens value for PT-DX800E and PT-DW730E. Values vary depending on the lens. Measurement,
measuring conditions and method of notation all comply with ISO21118 international standards.
*2: The maximum is 5.08 m (200") when using an ET-DLE055 lens.
*3: Average value. Weight varies for each product.
*4: When using the proje
ctor at high elevations 1 400 m (4 593 ft) – 2 700 m (8 858 ft) sea level, temperature will be 5
°
C
(41
°
F)
lower than this higher limit. If the projector is used with the following 2 settings when the ambient temperature reaches 40
°
C
(104
°
F) (35
°
C (95
°
F) in [HIGH ALTITUDE MODE]) or above, the light output may decrease by 20% to protect the projector.
– [LAMP SELECT] is set to [DUAL] in the menu
– [L
AMP
POWER] is set to [HIGH] in the menu
z
The part numbers of accessories and separately sold components are subject to change without notice.
