Specications
104 - ENGLISH
Appendix
The following table describes the specications of the projector.
Model No. PT-DW730E PT-DW730EL PT-DX800E PT-DX800EL
Power supply AC 220 V - 240 V 50 Hz/60 Hz
Power consumption
760 W
(When [STANDBY MODE] is set to [ECO]: 0.3 W
When [STANDBY MODE] is set to [NORMAL]: 9 W)
Amps 4.3 A
DLP
chip
Size 0.65" (aspect ratio 16:10) 0.7" (aspect ratio 4:3)
Display system One-unit DLP chip, DLP type
Number of pixels
1 024 000 pixels
(1 280 x 800 dots)
786 432 pixels
(1 024 x 768 dots)
Lens
Power
zoom 1.8 to 2.5:1
Optional
1.8 to 2.5:1
Optional
Power focus
F = 1.7 to 1.9
f = 25.6 mm
to 35.7 mm
F = 1.7 to 1.9
f = 25.6 mm
to 35.7 mm
Luminous lamp 300 W (maximum of 310 W) UHM lamp x 2
Light output 7 000 lm
*1
(ANSI) 8 000 lm
*1
(ANSI)
Applicable
scanning
frequency
For video
signals
(including
S-video)
Horizontal: 15.75 kHz/15.63 kHz, Vertical: 50 Hz/60 Hz
For RGB signals
Horizontal: 15 kHz to 91 kHz, Vertical: 50
Hz to 85 Hz
P
IAS (Panasonic Intelligent Auto Scanning) system
Dot clock frequency
150 MHz or less
For DVI-D
signals
525p(480p), 625p(576p), 750(720)/60p, 750(720)/50p,
1125(1080)/60p, 1125(1080)/50p, 1125(1080)/60i, 1125(1080)/50i,
1125(1080)/24sF, 1125(1080)/30p,
1125(1080)/25p, 1125(1080)/24p
z
Displayable resolution: VGA to WUXGA (non-interlaced)
z
Dot clock frequency: 25 MHz to 162 MHz
z
WUXGA signal
s support only VESA
CVT-RB (Reduced Blanking) signals.
For YP
B
P
R
signals
[525i (480i)] H: 15.75 kHz, V: 60 Hz
[525p (480p)] H: 31.5 kHz, V: 60 Hz
[750 (720)/60p] H: 45 kHz, V: 60 Hz
[1035/60i] H: 33.75 kHz, V: 60 Hz
[1125 (1080)/50i] H: 28.13 kHz, V: 50 Hz
[1125 (1080)/24p] H: 27 kHz, V: 24 Hz
[1125 (1080)/30p] H: 33.75 kHz, V: 30 Hz
[1125 (1080)/50p] H: 56.25 kHz, V: 50 Hz
[625i (576i)] H: 15.63 kHz, V: 5
0 Hz
[
625p (576p)] H: 31.25 kHz, V: 50 Hz
[750 (720)/50p] H: 37.5 kHz, V: 50 Hz
[1125 (1080)/60i] H: 33.75 kHz, V: 60 Hz
[1125 (1080)/25p] H: 28.13 kHz, V: 25 Hz
[1125 (1080)/24sF] H: 27 kHz, V: 48 Hz
[1125 (1080)/60p] H: 67.5 kHz, V: 60 Hz
z
SYNC/HD terminals and VD terminals are not supported in 3 value SYNC.
Color system 7 standards (NTSC/NTSC4.43/PAL/PAL-N/PAL-M/SECAM/PAL60)
Screen size 1.27 m (50") - 1
5.24 m (600")
*2
Screen aspect ratio 16:10 4:3
Projection method Front ceiling/front oor/rear ceiling/rear oor
Contrast ratio
2 500:1
(when [CONTRAST MODE] is set to [HIGH])
2 000:1
(when [CONTRAST MODE] is set to [HIGH])
Terminals RGB1 IN
1 set (BNC x 5)
[RGB SIGNAL] 0.7 V [p-p] 75
Ω
(SYNC ON GREEN: 1.0 V [p-p] 75
Ω
)
SYNC/HD, TTL high impedance, automatic positive/negative polarity
compatible
VD, TTL high impeda
nce, automatic positive/negative polarity compatible
[
YP
B
P
R
signal] Y:1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75
Ω
