Panasonic PT-DZ10K

As of April 2013
SFD12M023
2/17
S PEC F ILE
PT-DZ10K
3-Chip DLP
™
Projector
Specifications
Main unit
Power supply
Power consumption
DLP™ chip Panel size
Display method
Pixels
Lens
Lamp
Screen size
Brightness*
2
Center-to-corner uniformity*
2
Contrast*
2
Resolution
Scanning frequency SDI
HDMI/DVI-D/RGB
YP
B
P
R
(YC
B
C
R
)
120 V AC, 9 A, 50/60 Hz
220–240 V AC, 4.7 A, 50/60 Hz
925 W (1,010 VA) (0.2 W with standby mode set to eco.*
1
6 W with
standby mode set to normal. Both with fan stopped.)
900 W (980 VA) (0.3 W with standby mode set to eco.*
1
9 W with standby
mode set to normal. Both with fan stopped.)
24.4 mm (0.96 inches) diagonal (16:10 aspect ratio)
DLP™ chip × 3 (R, G, B), DLP™ projection system
2,304,000 (1,920 × 1,200) × 3, total of 6,912,000 pixels
Optional powered zoom/focus lenses
355 W UHM lamps (× 2) (dual lamp, normal mode)
1.78–25.4 m (70–1,000 inches) (1.78–15.24 m (70–600 inches) with the
ET-D75LE8), 16:10 aspect ratio
10,600 lumens (dual lamp, normal mode)
90%
10,000:1 (full on/full off, in dynamic iris 3 mode)
1,920 × 1,200 pixels
3G-SDI signal (RGB 4:4:4 12-bit/10-bit):
SMPTE ST 424 compliant: 1125(1080)/60i, 1125(1080)/50i,
1125(1080)/25p, 1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p
3G-SDI signal (YP
B
P
R
4:2:2 10-bit):
SMPTE ST 424 compliant: 1125(1080)/60p, 1125(1080)/50p
HD-SDI signal (YP
B
P
R
4:2:2 10-bit):
SMPTE ST 292 compliant: 750(720)/60p, 750(720)/50p, 1125(1035)/60i,
1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p, 1125(1080)/24p,
1125(1080)/24sF, 1125(1080)/30p
SD-SDI signal (YC
B
C
R
4:2:2 10-bit):
SMPTE ST 259 compliant: 525i(480i), 625i(576i)
Horizontal: 15 kHz–100 kHz, vertical: 24 Hz – 120 Hz,
dot clock: 25 –162 MHz or lower (HDMI/DVI: 25 MHz – 162 MHz)
525i (480i): f
H
15.75 kHz; f
V
60 Hz,
625i (576i): f
H
15.63 kHz; f
V
50 Hz,
525p (480p): f
H
31.50 kHz; f
V
60 Hz,
625p (576p): f
H
31.25 kHz; f
V
50 Hz,
750 (720)/60p: f
H
45.00 kHz; f
V
60 Hz,
750 (720)/50p: f
H
37.50 kHz; f
V
50 Hz,
1125 (1035)/60i: f
H
33.75 kHz; f
V
60 Hz,
1125 (1080)/60i: f
H
33.75 kHz; f
V
60 Hz,
1125 (1080)/50i: f
H
28.13 kHz; f
V
50 Hz,
1125 (1080)/25p: f
H
28.13 kHz; f
V
25 Hz,
1125 (1080)/24p: f
H
27.00 kHz; f
V
24 Hz,
1125 (1080)/24sF: f
H
27.00 kHz; f
V
48 Hz,
1125 (1080)/30p: f
H
33.75 kHz; f
V
30 Hz,
1125 (1080)/60p: f
H
67.50 kHz; f
V
60 Hz,
1125 (1080)/50p: f
H
56.25 kHz; f
V
50 Hz
120 V AC, 50/60 Hz
220–240 V AC, 50/60 Hz
f
H: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Video/S-Video
Optical axis shift Vertical
Horizontal
±55% (±44% with the ET-D75LE6) from center of screen, powered
±20% (±15% with the ET-D75LE6) from center of screen, powered
NOTE: Optical axis shift function cannot be operated when used with the
ET-D75LE50.
