Panasonic PT-REQ10 - Page 140

Chapter 4 Settings — [DISPLAY OPTION] menu
140 - ENGLISH
7) Press asqw to select [RESOLUTION].
f Select [1024x768p], [1280x720p], [1280x800p], [1280x1024p], [1366x768p], [1400x1050p], [1440x900p],
[1600x900p], [1600x1200p], [1680x1050p], [1920x1080p], [1920x1080i], [1920x1200p], [2048x1080p],
[2560x1080p], [2560x1440p], [2560x1600p], or [3840x2400p].
8) Press the <ENTER> button.
f The [VERTICAL SCAN FREQUENCY] screen is displayed.
9) Press qw to select [VERTICAL SCAN FREQUENCY].
f The setting is xed to [30Hz] when [3840x2400p] is selected for [RESOLUTION].
f Select [60Hz], [50Hz], [30Hz], [25Hz], or [24Hz] when [2048x1080p] is selected for [RESOLUTION].
f Select [120Hz], [60Hz], [50Hz], [30Hz], [25Hz], or [24Hz] when [1920x1080p] is selected for
[RESOLUTION].
f Select [60Hz], [50Hz], or [48Hz] when [1920x1080i] is selected for [RESOLUTION].
f Select [60Hz] or [50Hz] when anything other than following is selected for [RESOLUTION].
g [3840x2400p], [2048x1080p], [1920x1080p], [1920x1080i]
10) Press the <ENTER> button.
f The conrmation screen is displayed.
11) Press qw to select [OK], and press the <ENTER> button.
Note
f The settings in [RESOLUTION] and [VERTICAL SCAN FREQUENCY] are displayed in [EDID STATUS].
f The resolution and vertical scanning frequency settings may also be required on your computer or video device.
f The computer, video device, or projector in use may require the power to be turned o󰀨 and on again after conguring settings.
f A signal may not be output with the resolution and vertical scanning frequency that have been set, depending on your computer or video
device.
Setting [DIGITAL LINK OUT] in [SLOT IN] (DIGITAL LINK input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [DIGITAL LINK OUT].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[ENABLE]
Select this item to output the DIGITAL LINK signal (including the audio signal) input to the <DIGITAL
LINK IN/LAN> terminal from the <DIGITAL LINK OUT> terminal.
[DISABLE]
Select this item not to output the DIGITAL LINK signal from the <DIGITAL LINK OUT> terminal.
Note
f The DIGITAL LINK signal input to the <DIGITAL LINK IN/LAN> terminal is output from the <DIGITAL LINK OUT> terminal only when the
projector is in projection mode. It will not be output when the projector is in standby mode.
When the optional Wireless Presentation System Receiver Board (Model No.: TY-SB01WP) is
installed
Setting [SIGNAL LEVEL] in [SLOT IN] (PressIT input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SIGNAL LEVEL].
