Panasonic PT-REQ10 - Page 301

Chapter 7 Appendix — Specications
ENGLISH - 301
Signal
type
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
4K
division
Format
Color
format
Sampling
Horizontal
(kHz)
Vertical
(Hz)
V
3840 x 2160/24p
3 840 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 12bit
3 840 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 10bit
3 840 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 12bit
3 840 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 10bit
3 840 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 12bit
3840 x 2160/25p
3 840 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 12bit
3 840 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 10bit
3 840 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 12bit
3 840 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 RGB 4:4:4 10bit
3 840 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 RGB 4:4:4 12bit
3840 x 2160/30p
3 840 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 12bit
3 840 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 10bit
3 840 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 12bit
3 840 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 10bit
3 840 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 12bit
3840 x 2160/60p 3 840 x 2 160 135.0 60.0
*2
594.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 10bit
3840 x 2160/50p 3 840 x 2 160 112.5 50.0 594.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 10bit
4096 x 2160/24p
4 096 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160 54.0 24.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 12bit
4096 x 2160/25p
4 096 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160 56.3 25.0 297.0 IL 12G-SDI Type 1 RGB 4:4:4 12bit
4096 x 2160/30p
4 096 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 12bit
4 096 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 10bit
4 096 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 YP
B
P
R
4:4:4 12bit
4 096 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 10bit
4 096 x 2 160 67.5 30.0
*2
297.0 IL 12G-SDI Type 1 RGB 4:4:4 12bit
4096 x 2160/60p 4 096 x 2 160 135.0 60.0
*2
594.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 10bit
4096 x 2160/50p 4 096 x 2 160 112.5 50.0 594.0 IL 12G-SDI Type 1 YP
B
P
R
4:2:2 10bit
*1 This is supported when the optional Function Board for 12G-SDI Optical (Model No.: TY-SB01FB) is installed in the slot.
*2 The signal with 1/1.001x vertical scanning frequency is also supported.
