Panasonic PT-RZ21K

24/25
CONTROL COMMANDS
2017/12/21
CONTROL
QUERY
RZ21K SERIES
CATEGORY FUNCTION Parameter/Name Sub-Parameter
COMMANDS COMMANDS CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
Focus Magenta
Focus Yellow
Focus
3D-1
3D-2
3D-3
3D-4
OTS:74
OTS:75
OTS:78
OTS:80
OTS:81
OTS:82
OTS:83
74
75
78
80
81
82
83
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SIGNAL
LIST
SIGNAL LIST-REGISTRATION
OEM
✔ ✔
SIGNAL LIST-DELETE
A1
A2
A7
A8
L1
L2
L7
L8
ODM:A1
ODM:A2
ODM:A7
ODM:A8
ODM:L1
ODM:L2
ODM:L7
ODM:L8
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
SUB MEMORY LIST-CHANGEOVER
01
96
OCS:01
OCS:96
✔
✔
✔
✔
SUB MEMORY LIST-CHANGEOVER
(EXTENDED)
01
96
OCS:01-01
OCS:95-96
✔
✔
✔
✔
SUB MEMORY LIST-REGISTRATION
OES
✔ ✔
SUB MEMORY LIST-DELETE
01
96
ODS:01-01
ODS:95-96
✔
✔
✔
✔
SUB MEMORY USAGE STATE
01
96
QSB 01
96
✔
✔
✔
✔
SECURITY
SECURITY SETTING
OFF
ON
QVX:SPWI1 SPWI1=+00000
SPWI1=+00001
✔
✔
✔
✔
CONTROL DEVICE SETUP-
CONTROL PANEL
DISABLE
ENABLE
USER
VXX:CDSI1=+00000
VXX:CDSI1=+00001
VXX:CDSI1=+00002
QVX:CDSI1 CDSI1=+00000
CDSI1=+00001
CDSI1=+00002
✔
✔
✔
✔
✔
✔
CONTROL DEVICE SETUP-REMOTE
CONTROL
DISABLE
ENABLE
USER
VXX:CDSI2=+00000
VXX:CDSI2=+00001
VXX:CDSI2=+00002
QVX:CDSI2 CDSI2=+00000
CDSI2=+00001
CDSI2=+00002
✔
✔
✔
✔
✔
✔
NETWORK
DIGITAL LINK MODE
AUTO
DIGITAL LINK
ETHERNET
LONG REACH MODE
VXX:DKMI1=+00001
VXX:DKMI1=+00002
VXX:DKMI1=+00003
VXX:DKMI1=+00004
QVX:DKMI1 DKMI1=+00001
DKMI1=+00002
DKMI1=+00003
DKMI1=+00004
✔
✔
✔
✔
✔
✔
✔
✔
DIGITAL LINK-DUPLEX(Ethernet)
Auto negotiation
100BaseTX-Full
100BaseTX-Half
VXX:DKDI1=+00000
VXX:DKDI1=+00001
VXX:DKDI1=+00002
QVX:DKDI1 DKDI1=+00000
DKDI1=+00001
DKDI1=+00002
✔
✔
✔
✔
✔
✔
DIGITAL LINK-DUPLEX(DIGITAL
LINK)
Auto negotiation
100BaseTX-Full
100BaseTX-Half
VXX:DKDI2=+00000
VXX:DKDI2=+00001
VXX:DKDI2=+00002
QVX:DKDI2 DKDI2=+00000
DKDI2=+00001
DKDI2=+00002
✔
✔
✔
✔
✔
✔
DIGITAL LINK STATUS-LINK
NO LINK
DIGITAL LINK
LPM
ETHERNET
QVX:DKSI1 DKSI1=+00000
DKSI1=+00001
DKSI1=+00002
DKSI1=+00003
✔
✔
✔
✔
✔
✔
✔
✔
DIGITAL LINK STATUS-HDCP
STATUS
NO SIGNAL
OFF
ON
QVX:DKSI2 DKSI2=+00000
DKSI2=+00001
DKSI2=+00002
✔
✔
✔
✔
✔
✔
DIGITAL LINK STATUS-SIGNAL
QUALITY (MIN)
-255
0
QVX:DKSI3 DKSI3=-00255
DKSI3=+00000
✔
✔
✔
✔
