Panasonic PT-RZ21K

7/25
CONTROL COMMANDS
2017/12/21
CONTROL
QUERY
RZ21K SERIES
CATEGORY FUNCTION Parameter/Name Sub-Parameter
COMMANDS COMMANDS CALL BACK
RZ21K
SRZ21KC
RS20K
SRS20KC
ADVANCED
TOTAL LINES
2047
VTL:2047 2047
✔ ✔
INPUT RESOLUTION-
DISPLAY LINES
150
2037
VDL:0150
VDL:2037
QDL 0150
2037
✔
✔
✔
✔
CLAMP POSITION
1
255
VLT:001
VLT:255
QLT 001
255
✔
✔
✔
✔
CUSTOM MASKING *
OFF
PC-1
PC-2
PC-3
VXX:MSKI1=+00000
VXX:MSKI1=+00001
VXX:MSKI1=+00002
VXX:MSKI1=+00003
QVX:MSKI1 MSKI1=+00000
MSKI1=+00001
MSKI1=+00002
MSKI1=+00003
✔
✔
✔
✔
✔
✔
✔
✔
EDGE BLENDING
OFF
ON
USER
VXX:EDBI0=+00000
VXX:EDBI0=+00001
VXX:EDBI0=+00002
QVX:EDBI0 EDBI0=+00000
EDBI0=+00001
EDBI0=+00002
✔
✔
✔
✔
✔
✔
EDGE BLENDING-UPPER ON/OFF
OFF
ON
VGU:0
VGU:1
QGU 0
1
✔
✔
✔
✔
EDGE BLENDING-LOWER ON/OFF
OFF
ON
VGB:0
VGB:1
QGB 0
1
✔
✔
✔
✔
EDGE BLENDING-LEFT ON/OFF
OFF
ON
VGL:0
VGL:1
QGL 0
1
✔
✔
✔
✔
EDGE BLENDING-RIGHT ON/OFF
OFF
ON
VGR:0
VGR:1
QGR 0
1
✔
✔
✔
✔
EDGE BLENDING-START-UPPER
min.
max.
VEU:0000
VEU:2272
QEU 0000
2272
0
1023
0
1023
EDGE BLENDING-START-LOWER
min.
max.
VEB:0000
VEB:2272
QEB 0000
2272
0
1199
0
1199
EDGE BLENDING-START-LEFT
min.
max.
VEL:0000
VEL:3712
QEL 0000
3712
0
1023
0
1023
EDGE BLENDING-START-RIGHT
min.
max.
VER:0000
VER:3712
QER 0000
3712
0
1919
0
1919
EDGE BLENDING-WIDTH-UPPER
min.
max.
VXX:EUWI0=+00000
VXX:EUWI0=+02272
QVX:EUWI0 EUWI0=+00000
EUWI0=+02272
0
1023
0
1023
EDGE BLENDING-WIDTH-LOWER
min.
max.
VXX:EBWI0=+00000
VXX:EBWI0=+02272
QVX:EBWI0 EBWI0=+00000
EBWI0=+02272
0
1199
0
1199
EDGE BLENDING-WIDTH-LEFT
min.
max.
VXX:ELWI0=+00000
VXX:ELWI0=+03712
QVX:ELWI0 ELWI0=+00000
ELWI0=+03712
0
1023
0
1023
EDGE BLENDING-WIDTH-RIGHT
min.
max.
VXX:ERWI0=+00000
VXX:ERWI0=+03712
QVX:ERWI0 ERWI0=+00000
ERWI0=+03712
0
1919
0
1919
EDGE BLENDING-MARKER-ON/OFF
OFF
ON
VGM:0
VGM:1
QGM 0
1
✔
✔
✔
✔
EDGE BLENDING-NON-
OVERLAPPED BLACK LEVEL
0 (W,R,G,B)
255 (W,R,G,B)
VJI:000.000.000.000
VJI:255.255.255.255
QJI 000.000.000.000
255.255.255.255
✔
✔
✔
✔
EDGE BLENDING-NON-
OVERLAPPED BLACK LEVEL-
OFF
ON
VXX:EBII1=+00000
VXX:EBII1=+00001
QVX:EBII1 EBII1=+00000
EBII1=+00001
✔
✔
✔
✔
EDGE BLENDING-BLACK BORDER
LEVEL
0 (W,R,G,B)
255 (W,R,G,B)
VJO:000,000,000,000
VJO:255,255,255,255
QJO 000.000.000.000
255.255.255.255
✔
✔
✔
✔
EDGE BLENDING-BLACK BORDER
LEVEL-INTERLOCKED
OFF
ON
VXX:EBII2=+00000
VXX:EBII2=+00001
QVX:EBII2 EBII2=+00000
EBII2=+00001
✔
✔
✔
✔
EDGE BLENDING-BLACK BORDER
WIDTH-UPPER
min.
max.
VJU:0000
VJU:2272
QJU 0000
2272
0
1023
0
1023
EDGE BLENDING-BLACK BORDER
WIDTH-LOWER
min.
max.
VJB:0000
VJB:2272
QJB 0000
2272
0
1199
0
1199
EDGE BLENDING-BLACK BORDER
WIDTH-LEFT
min.
max.
VJL:0000
VJL:3712
QJL 0000
3712
0
1023
0
1023
