S P E C F I L E
PT-VW431D
LCD Projector
As of September 2012
SFL12M015
5 / 1 3
Standard setting-up position
Projected image
Lower edge of projected image
Upper edge of projected image
Projected image
921– 1,491
(36-1/4 – 58-11/16)
Adjustable in
30 mm
(1-3/16-inch) step.
143
∅ 38
(5-5/8)
162
(6-3/8)
(1-1/2)
70
(2-3/4)
100
(3-15/16)
100
(3-15/16)
200
(7-7/8)
140
(5-1/2)
70
(2-3/4)
85
(3-11/32)
L
L
L
HH
unit : mm (inch)
NOTE:
Illustrations show the projector
installed using optional ceiling mount
bracket ET-PKV100H and bracket
assembly ET-PKV200B.
This illustration is not drawn to scale.
0.76 m
1.02 m
1.27 m
1.52 m
1.78 m
2.03 m
2.29 m
2.54 m
3.05 m
3.81 m
5.08 m
6.35 m
7.62 m
0.7
1.0
1.3
1.5
1.8
2.0
2.3
2.5
3.1
3.8
5.1
6.4
7.7
1.2
1.6
2.0
2.5
2.9
3.3
3.7
4.1
4.9
6.2
8.3
10.3
12.4
0.01
0.01
0.01
0.02
0.02
0.02
0.02
0.03
0.03
0.04
0.05
0.07
0.08
0.20
0.27
0.34
0.40
0.47
0.54
0.61
0.67
0.81
1.01
1.35
1.68
2.02
−
−
−
−
−
−
−
−
−
−
−
−
−
30˝
40˝
50˝
60˝
70˝
80˝
90˝
100˝
120˝
150˝
200˝
250˝
300˝
/
/
/
/
/
/
/
/
/
/
/
/
/
(2.3)
(3.3)
(4.3)
(4.9)
(5.9)
(6.6)
(7.5)
(8.2)
(10.2)
(12.5)
(16.7)
(21.0)
(25.3)
(3.9)
(5.2)
(6.6)
(8.2)
(9.5)
(10.8)
(12.1)
(13.5)
(16.1)
(20.3)
(27.1)
(33.9)
(40.6)
(0.03
(0.03
(0.03
(0.07
(0.07
(0.07
(0.07
(0.10
(0.10
(0.13
(0.16
(0.23
(0.26
0.66)
0.89)
1.12)
1.31)
1.54)
1.77)
2.00)
2.20)
2.66)
3.31)
4.43)
5.51)
6.63)
−
−
−
−
−
−
−
−
−
−
−
−
−
Projection size
[diagonal]
Projection distance [L]
Min [wide] Max [telephoto]
P
Height from the edge of screen
to center of lens [H]
Projection distance for 16:10 aspect ratio screen
unit: meters (feet)
NOTE:
• The value for L (distance to screen) varies slightly depending on the zoom lens characteristics.
• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.
C a u t i o n :
• All construction work should be done by a qualified technician.
• When mounting to the ceiling, use the special mounting bracket. To prevent the projector from dropping, attach
the wire that is included with the projector between the mounting bracket and the ceiling.
