Panasonic PT-VW431DE

Operating Instructions
Functional Manual
LCD Projector
Commercial Use
Thank you for purchasing this Panasonic Product.
Before operating this product, please read the instructions carefully, and save this manual
J
for future use.
Before using your projector, be sure to read “Read this rst!” (
J
Æ
pages 2 to 6).
Model No.
PT-VW431DE
ENGLISH
LL4AC

Panasonic PT-VW431DE Specifications

General

Brand	Panasonic
Model	PT-VW431DE
Category	Projector
Language	English

Summary

Read This First!

Projector Features and Quick Steps

Precautions for Use

Transport and Installation Cautions

Guidelines for safely transporting and installing the projector.

Precautions for Use (Continued)

About Your Projector

About Your Projector (Continued)

Setting Up the Projector

Setting Up the Projector (Continued)

Screen Size and Throw Distance Chart

Provides a table detailing projection distances for various screen sizes and aspect ratios.

Projector Connections

Powering the Projector ONOFF

Connecting the Power Cord Securely

Step-by-step instructions for attaching and securing the power cord to the projector.

Powering the Projector ONOFF (Continued)

Understanding the ONSTANDBY Indicator

Explains the different states and colors of the projector's power indicator light.

Turning On the Projector Procedure

Detailed steps for powering on the projector, including initial display and input selection.

Entering the Projector PIN Code

Instructions for entering the PIN code if the projector is locked for security.

Turning Off the Projector Procedure

Steps for safely powering off the projector and cooling down the lamp.

Using the Direct Power Off Function

How to disconnect power without using the standard power-off sequence.

Projecting an Image

Selecting the Input Signal Source

How to choose the desired input signal for projection from various sources.

Adjusting Image State and Position

Steps for adjusting projection angle, lens shift, zoom, and focus for optimal image.

Basic Operations with Remote Control

Using AUTO SETUP and Input Selection

How to automatically adjust computer input and switch between input signals.

Basic Operations with Remote Control (Continued)

Keystone and Information Display Functions

How to correct keystone distortion and display projector information using the remote.

AV MUTE, LAMP, and D.ZOOM Functions

Explains the AV MUTE, LAMP mode selection, and digital zoom functions.

Using the IMAGE and MUTE Buttons

How to select image modes and mute the sound using the remote control.

Menu Navigation Guide

Navigating the On-Screen Menu System

Step-by-step guide on how to access and navigate the projector's menu system.

Menu Navigation Guide (Continued)

Understanding Main and Sub Menus

Overview of the main menu structure and sub-menu items for configuration.

Input Menu Configuration

Setting Up Computer, Video, and HDMI Inputs

Guides on configuring various input sources like Computer 1/2, Video, HDMI, and DIGITAL LINK.

Input Menu Configuration (Continued)

Video and Component Input Signal Settings

How to set color systems for Video/S-Video and scanning methods for Component input.

AUTO PC Adjust Function

Performing Automatic PC Adjustment

How to use the auto PC adjustment feature to optimize computer input signals.

Storing PC Adjustment Parameters

Steps to save the adjusted PC settings for future use.

Manual PC Adjustments

Horizontal, Vertical, and Fine Sync Adjustments

Detailed instructions for manually adjusting image position and synchronization.

Manual PC Adjustments (Continued)

Current Mode, Clamp, and Display Area Settings

Adjusting current mode, clamp level, and display area H/V.

Image Select Modes

Image Adjustment Settings

Adjusting Contrast and Brightness

How to fine-tune image contrast and brightness levels.

Adjusting Color and Tint

Steps for adjusting color saturation and hue for optimal color balance.

Image Adjustment Settings (Continued)

Sharpness and Gamma Adjustment

Fine-tuning sharpness for image clarity and gamma for contrast balance.

Screen Settings

Normal, Full, and Wide(16:9) Screen Modes

Options for fitting the image to the screen while maintaining aspect ratio.

Screen Settings (Continued)

Custom Screen Adjustments

Manually adjusting screen scale and position, saving custom settings.

Ceiling, Rear, and Aspect Ratio Settings

Settings for ceiling/rear projection and adjusting screen aspect ratio.

Digital Zoom and Keystone Correction

How to use digital zoom and correct keystone distortion.

Sound Settings

Volume, Mute, and MIC Controls

Adjusting speaker volume, muting audio, and configuring the microphone input.

Setting Menu Options

Language, Menu Position, and Auto Setup

Configuring display language, menu location, and auto setup features.

Auto PC and Keystone Adjustment Settings

Settings for automatic PC adjustment and auto keystone correction.

Setting Menu Options (Continued)

HDMI, DIGITAL LINK, and Terminal Settings

Configuring HDMI input, DIGITAL LINK signal, and terminal output settings.

Power Management States and Timer Settings

Managing power states (Off, Ready, Shut Down) and setting timers.

PIN Code Lock and Change Procedures

Setting or changing the PIN code for projector security.

Video Delay and Filter Counter Settings

Adjusting video delay and setting filter replacement frequency.

RS232 C Serial Control Settings

Direct On, Standby Mode, and P-Timer Settings

Configuring direct power-on, standby modes, and the P-Timer function.

Information Menu Display

Input Source Information Overview

Network Settings Overview

DIGITAL LINK Mode and Setup

Network Settings Configuration

Network Mode and IP Address Settings

Network Settings Configuration (Continued)

Network Control and Status Information

Network Settings via Computer

Computer Operation and Network Configuration

Accessing Projector via Web Browser

Network Control Interface

Projector Control Window Description

Network Control Interface (Continued)

Error Information Display

Basic Control Page Operations

Network Configuration and Ping Test Pages

E-mail Setup Page Configuration

E-mail Setup Page Details

Change Password Page Overview

CRESTRON RoomView Operation

LAMP and WARNING Indicators

Managing Projector Status Indicators

Explains how to interpret and manage the LAMP and WARNING indicator lights.

Replacement Procedures

Before Replacing Unit and Basic Maintenance

Replacement Procedures (Continued)

Replacing Air Filter Units (Side and Back)

Lamp Unit Information and Replacement Notes

Details about the lamp unit, its replacement, and important cautions.

Replacing the Lamp Unit Step-by-Step

Detailed instructions for safely removing and installing a new lamp unit.

When to Replace the Lamp Unit

Troubleshooting Common Issues

Power and Picture Display Problems

Solutions for power-on issues, no picture, fuzzy image, and color problems.

Sound and Remote Control Problems

Troubleshooting audio issues, remote control not operating, and button malfunctions.

Troubleshooting Common Issues (Continued)

Computer and HDMI Connectivity Issues

Solutions for computer display problems, HDMI picture instability, and audio output.

DIGITAL LINK and Service Error Troubleshooting

Resolving issues with DIGITAL LINK input and service errors indicated on the screen.

Technical Information - PJLink Protocol

Understanding PJLink Protocol Capabilities

PJLink Control Commands Overview

Technical Information - LAN Control Commands

LAN Connection and Command Transmission Methods

Technical Information - LAN Control Commands (Continued)

Non-Protect Mode LAN Connection Details

Technical Information - Serial Terminal Control

Serial Terminal Connection and Pin Assignments

Technical Information - Command Formats

Basic Command Transmission Format

Technical Information - Cable Specifications and Commands

Cable Specifications for Computer Connection

Projector Control Commands List

Technical Information - Terminal Pin Assignments

Other Terminal Pin Assignments

S-Video Terminal Pin Assignments

Computer 1 Component Terminal Pin Assignments

Computer 2 Monitor Out Terminal Pin Assignments

HDMI Terminal Pin Assignments

Technical Information - Compatible Signals

List of Compatible Video Signals

Technical Information - Compatible Signals (Continued)

List of Compatible Video Signals (Continued)

Projector Specifications

General and Power Specifications

Details model number, power supply, consumption, and panel specifications.

LCD Panel, Lens, and Lamp Specifications

Information on LCD panel type, lens details, lamp type, and light output.

Signal Frequency and Input Compatibility

Projector Specifications (Continued)

Terminal and Cable Specifications

Pin assignments and specifications for various projector terminals and cables.

Cabinet, Dimensions, and Operating Environment

Ceiling Mount Bracket Installation Safeguards
