About Your Projector
16
- ENGLISH
Preparation
(1) Remote control signal receiver
(2) Focus Lever
(
Æ
page 30)
Adjust the focus.
(3) Projection Lens
(4) Zoom Lever
(
Æ
page 30)
Adjust the zoom.
(5) Vertical lens shift ring
(
Æ
page 23)
Adjust the vertical position of the projected
image.
(6) Control Panel and Indicators
(
Æ
page 17)
(7) Lamp cover
(
Æ
page 81)
The lamp unit is located inside.
(8) Air outlet port
Hot air is exhausted from the exhaust vent. Do
•
not put heat-sensitive objects near this side.
(9) Speaker
(10) AC IN
(11) Rear terminals
(
Æ
page 18)
(12) Air intake port / Air lter cover
(
Æ
page 78)
(13) Adjustable feet
Adjust the projection angle.
WARNING:
Keep your hands and other objects away from
the air exhaust port
.
Keep your hand and face away.
z
Do not insert your nger.
z
Keep heat-sensitive articles away.
z
Heated air from the air exhaust port can cause burns
or external damage.
Projector body
(5)
(4)
(1) (2)
(3)
(6)
(8)
(10)
(11)
(12)
(7)
(9)
(13)
To Next Page
