[POSITION] menu
On the menu screen, select [POSITION] from the main menu, and select an item from the submenu.
Refer to "Navigating through the menu" (Æpage 54) for the operation of the menu screen.
fAfter selecting the item, press asqw to set.
[KEYSTONE]
You can correct the trapezoidal distortion that occurs when the projector is installed tilted or when the screen is tilted.
1) Press as to select [KEYSTONE].
2) Press the <ENTER> button.
f The [KEYSTONE] screen is displayed.
3) Press as to select one item to adjust.
[KEYSTONE]
Adjusts when the trapezoid of the projected image is distorted.
[CORNER CORRECTION]
Adjusts when the four corners of the projected image are distorted.
[KEYSTONE]
1) Press as to select [KEYSTONE].
2) Press the <ENTER> button.
f The [KEYSTONE] screen is displayed.
3) Press as to select [KEYSTONE].
4) Press the <ENTER> button.
f The [KEYSTONE] individual adjustment screen is displayed.
5) Press asqw to adjust the item.
Items Operation Adjustment Adjustment range
[HORIZONTAL]
Press the w button.
Adjusts the right of
the keystone.
-60 ~ +60
Press the q button.
Adjusts the left of
the keystone.
[VERTICAL]
Press the a button.
Adjusts the upper
of the keystone.
-80 ~ +80
Press the s button.
Adjusts the bottom
of the keystone.
ENGLISH - 63
Chapter 4 Settings - [POSITION] menu
