Notes:
Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 L6FALEFH0030 FAN UNIT [M]
2 REEX0212-2 14P FFC WIRE [M]
3 REEX0503 10P FFC WIRE [M]
4 REEX0513 17P FFC WIRE [M]
5 REEX0528 14P FFC WIRE [M]
6 REEX0529 30P FFC WIRE [M]
7 RGKX0319-KJ TOP ORNAMENT [M]
8 RGKX0320D-KJ CD LID [M]
10 RGLX0121-Q POWER LIGHT PIECE [M]
11 RGPX0207C-S1 FRONT PANEL [M]
12 RGRX0054F-A REAR PANEL [M]E
12 RGRX0054F-B REAR PANEL [M]EB
12 RGRX0054F-C REAR PANEL [M]EG
13 RGUX0637-SJ POWER/DISC BUTTON [M]
14 RGUX0638-SJ OPEN DECK 1 BUTTON [M]
15 RGUX0639-SJ OPEN DECK 2 BUTTON [M]
16 RGUX0640-SJ DISC/OPEN/5CD BUTTON [M]
17 RGUX0642-SJ FUNCTION BUTTON L [M]
18 RGUX0643-SJ FUNCTION BUTTON R [M]
19 RGUX0644-KJ CONTROL BUTTON [M]
20 RGWX0094-S VOLUME KNOB [M]
21 RHD26046-L SCREW [M]
22 RHD30007-1SJ SCREW [M]
23 RHD30111-3 SCREW [M]
24 RHD30119-S SCREW [M]
25 RKA0072-KJ LEG CUSHION [M]
26 RKFX0131-SJ CASS LID L [M]
27 RKFX0132-SJ CASS LID R [M]
28 RKMX0117-SJ TOP PANEL (BEND) [M]
29 RKWX0253-H FL WINDOW [M]
30 RMBX0036 CASS OPEN SPRING [M]
31 RMBX0049 CD LID OPEN SPRING [M]
33 RMCX0021-J TRANSISTOR CLIP [M]
34 RMG0547-K CUSHION [M]
Ref. No. Part No. Part Name & Description Remarks
35 XTWS3+6TFJ SCREW [M]
36 RMGX0044 D.AMP.IC INSULATOR [M]
37 RMKX0112 BOTTOM CHASSIS [M]
38 RMKX0113 CD CHASSIS [M]
40 RMNX0163 FL HOLDER [M]
42 XTW3+10TFC SCREW [M]
43 RMVX0092A FL WINDOW BACKGROUND [M]
45 RUS757ZAA CASS HALF SPRING [M]
46 XTV3+10GFJ-M SCREW [M]
47 RXGX0002 DAMPER GEAR [M]
48 RXXX0066A HEAT SINK UNIT [M]
49 XTW3+12TFJ SCREW [M]
51 RSQX0006 D/SHIELD PLATE UNIT [M]
CASSETTE DECK
101 RED0069-2 R/P HEAD BLOCK UNIT [M]
102 RED0070-1 P/B HEAD BLOCK UNIT [M]
103 RDG0300 REEL BASE GEAR [M]
104 RDG0301 WINDING RELAY GEAR [M]
105 RDK0026-4 MAIN GEAR [M]
107 RDV0033-4 WINDING BELT [M]
108 RDV0064-1 CAPSTAN BELT [M]
109 RDV0071-2 CAPSTAN BELT B [M]
110 RMB0312 TRIGGER LEVER SPRING [M]
111 RMB0400 REEL SPRING [M]
112 RMB0403 HEAD PANEL SPRING [M]
113 RMB0404 BRAKE ROD SPRING [M]
114 RMB0406-5 FR LEVER SPRING [M]
115 RMB0408 THRUST SPRING [M]
116 RML0370-4 TRIGGER LEVER [M]
117 RML0371 FR LEVER [M]
118 RML0372-2 WINDING LEVER [M]
119 RML0374-2 EJECT LEVER [M]
120 RMM0131-1 BRAKE ROD [M]
121 RMM0133-1 EJECT ROD [M]
22 Replacement Parts List
·
Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
·
T he parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
·
Warning: This product uses a laser diode. Refer to caution statements on “Precaution of Laser Diode”.
ACHTUNG:
−
− −
− Die Lasereinheit nicht zerlegen.
−
− −
− Die Lasereinheit darf nur gegen eine vom Hertsteller spezifizierte Einheit ausgetauscht werden.
·
Capacitor values are in microfarads (µF) unless specified otherw ise, P= Pico-farads (pF), F= Farads.
·
Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
·
The marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assem bly will no longer be available.
·
[M] Indicates in the Remarks columns indicates parts supplied by PAVCSG.
·
Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian
95
SA-AK240E / SA-AK240EB / SA-AK240EG
