Ref. No. Part No. Part Name & Description Remarks
122 RMQ0519 REEL HUB [M]
123 RMS0398-1 MOVING CORE [M]
124 RSJ0003 PLUNGER ASS’Y [M]
125 RMC0061 PACK SPRING [M]
126 RXF0061-1 FLYWHEEL F ASS’Y [M]
128 RXG0040 FF RELAY GEAR ASS’Y [M]
129 RMK0283A-2 SUB-CHASSIS [M]
130 RXL0124 PINCH ROLLER F ASS’Y [M]
130-1 RMB0401 PINCH ARM SPRING F [M]
132 RXL0126 WINDING ARM ASS’Y [M]
133 RXQ0412-3 HEAD PANEL ASS’Y [M]
133-1 RMB0405-1 FR ROD SPRING [M]
133-2 RMM0132-1 FR ROD [M]
134 REM0121 CAP MOTOR ASS’Y [M]
135 RHD26022-1 MOTOR SCREW [M]
136 XTW2+5LFJ HEAD BLOCK UNIT SCREW [M]
137 XTW26+10SFJ SUB-CHASSIS SCREW [M]
138 XYC2+JF17FJ PCB EARTH SCREW [M]
139 RFKJAA4501-S CHASSIS ASS’Y [M]
TRAVERSE DECK
358 RFKNCT121157 SPINDLE MOTOR ASS’Y [M]
358-1 RXQ0632 TRAVERSE MOTOR UNIT [M]
358-2 XQN17+C28FJ SCREW [M]
359 RDG0455 TRAVERSE GEAR (A) [M]
360 RDG0456 TRAVERSE GEAR (B) [M]
361 RXQ0999 OPU UNIT [M]
362 RMM0218 TRAVERSE DRIVE RACK [M]
363 SNSD38-1 SCREW [M]
364 RMS0757-1 FIXED PIN [M]
365 RMG0703-R FLOATING RUBBER [M]
366 RME0109 FLOATING SPRING [M]
367 XTN2+6GFJ SCREW [M]
368 RMRX0064 MIDDLE CHASSIS [M]
369 RAE0157A-V TRV UNIT WITHOUT SERVO [M]
PRINTED CIRCUIT BOARD
REPX0494A CD SERVO P.C.B. [M]
REPX0516N MAIN P.C.B. [M]
REPX0517N PANEL P.C.B. [M]
REPX0518K TRANSFORMER P.C.B. [M]
REPX0533B POWER P.C.B. [M]
REPX0331G DECK P.C.B. [M]
REPX0321A DECK MECHANISM P.C.B. [M]
INTEGRATED CIRCUITS
IC951 CNB13030R2AU IC PHOTO INTERRUPTER [M]
IC971 CNB13030R2AU IC PHOTO INTERRUPTER [M]
IC1001 AN7348S-E1 IC P.B. EQ/REC AMP/ALC/TPS
AMP
[M]
IC1004 C1AA00000612 IC R.P. SELECT [M]
IC2601 C1BB00000962 IC FM/AM IF AMP,DET/AM
OSC,MIX/FM MPX
[M]
IC2602 C1CB00001937 IC PLL FREQUENCY
SYNTHESIZER
[M]
IC2801 C2CBYY000053 IC MICROPROCESSOR [M]
IC2803 C1BB00001121 IC AUDIO SOUND PROCESSOR [M]
IC2804 C0AABB000125 IC DUAL OP-AMP [M]
IC2809 C1BB00000987 IC RDS [M]
IC5201 C0JBAB000011 IC LOGIC [M]
IC5301 C1BA00000407 IC 2-CH DIGITAL AMP [M]
IC6601 C0HBB0000057 IC FL DRIVER [M]
IC7001 MN6627954MA IC SERVO PROCESSOR/DIGITAL
SIGNAL PROCESSOR/DIGITAL
FILTER D/A CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Q1003 B1AAGC000007 TRANSISTOR [M]
Q1004 B1AAGC000007 TRANSISTOR [M]
Q1005 B1AAGC000007 TRANSISTOR [M]
Ref. No. Part No. Part Name & Description Remarks
Q1007 B1ABCF000176 TRANSISTOR [M]
Q1017 B1AARC000003 TRANSISTOR [M]
Q2142 B1ABCF000176 TRANSISTOR [M]
Q2242 B1ABCF000176 TRANSISTOR [M]
Q2311 B1ABGC000005 TRANSISTOR [M]
Q2317 B1ABGC000005 TRANSISTOR [M]
Q2341 B1ABGC000005 TRANSISTOR [M]
Q2411 B1ABGC000005 TRANSISTOR [M]
Q2417 B1ABGC000005 TRANSISTOR [M]
Q2441 B1ABGC000005 TRANSISTOR [M]
Q2511 B1GDCFJJ0047 TRANSISTOR [M]
Q2601 B1AABC000003 TRANSISTOR [M]
Q2606 B1GCCFJJ0016 TRANSISTOR [M]
Q2610 2SC3311ARA TRANSISTOR [M]
Q2803 B1GBCFJJ0051 TRANSISTOR [M]
Q2901 B1ACKD000006 TRANSISTOR [M]
Q2902 B1AACF000064 TRANSISTOR [M]
Q2906 B1ABCF000176 TRANSISTOR [M]
Q2907 B1ABCF000176 TRANSISTOR [M]
Q2936 B1ACKD000006 TRANSISTOR [M]
Q2937 B1GBCFJJ0051 TRANSISTOR [M]
Q2942 B1ACKD000006 TRANSISTOR [M]
Q2943 B1ABCF000176 TRANSISTOR [M]
Q2948 B1ABCF000176 TRANSISTOR [M]
Q2949 B1ABCF000176 TRANSISTOR [M]
Q2950 B1ACKD000006 TRANSISTOR [M]
Q2951 B1ACKD000006 TRANSISTOR [M]
Q2952 B1GBCFLL0037 TRANSISTOR [M]
Q2957 B1GBCFLL0037 TRANSISTOR [M]
Q2958 B1ACKD000006 TRANSISTOR [M]
Q2959 B1GBCFLL0037 TRANSISTOR [M]
Q2960 B1ACKD000006 TRANSISTOR [M]
Q2978 B1GDCFJJ0047 TRANSISTOR [M]
Q2980 B1GDCFJJ0047 TRANSISTOR [M]
Q5101 B1CEGM000001 TRANSISTOR [M]
Q5102 B1CEGM000001 TRANSISTOR [M]
Q5103 B1ABCF000176 TRANSISTOR [M]
Q5104 B1ABCF000176 TRANSISTOR [M]
Q5108 B1ABCF000176 TRANSISTOR [M]
Q5109 2SB0709AHL TRANSISTOR [M]
Q5110 B1AACF000064 TRANSISTOR [M]
Q5111 B1BACG000023 TRANSISTOR [M]
Q5112 B1BCCG000002 TRANSISTOR [M]
Q5113 B1GDCFNA0001 TRANSISTOR [M]
Q5114 B1ABCF000176 TRANSISTOR [M]
Q5115 B1AAKD000014 TRANSISTOR [M]
Q5153 B1ABCF000176 TRANSISTOR [M]
Q5154 2SB0709AHL TRANSISTOR [M]
Q5173 B1ABCF000176 TRANSISTOR [M]
Q5201 B1ABCF000176 TRANSISTOR [M]
Q5202 B1ADCF000063 TRANSISTOR [M]
Q5950 B1AAKD000014 TRANSISTOR [M]
Q5951 2SB0621AHA TRANSISTOR [M]
Q5952 B1GACFJJ0018 TRANSISTOR [M]
Q5953 B1AACF000064 TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
DIODES
D951 MA2C16500E DIODE [M]
D971 MA2C16500E DIODE [M]
D1003 B0ACCK000005 DIODE [M]
D2191 B0ACCK000005 DIODE [M]
D2241 B0ACCK000005 DIODE [M]
D2583 B0BC9R000008 DIODE [M]
D2601 B0BC5R000009 DIODE [M]
D2602 B0CDBB000015 DIODE [M]
D2677 B0BC7R500001 DIODE [M]
D2801 B0ACCK000005 DIODE [M]
D2803 B0ACCK000005 DIODE [M]
D2811 B0ADCJ000020 DIODE [M]
D2813 B0ACCK000005 DIODE [M]
D2901 B0ADCC000002 DIODE [M]
D2936 B0EAKM000117 DIODE [M]
