Panasonic SA-AK240E - Page 97

Ref. No. Part No. Part Name & Description Remarks
D2946 B0ADCJ000020 DIODE [M]
D2950 B0ACCK000005 DIODE [M]
D5101 B0BA01100004 DIODE [M]
D5102 B0BA02600018 DIODE [M]
D5103 B0BA3R900006 DIODE [M]
D5104 B0BA01100004 DIODE [M]
D5105 B0BA02400029 DIODE [M]
D5107 B0BA01500003 DIODE [M]
D5108 B0BA5R700008 DIODE [M]
D5109 B0BA01100004 DIODE [M]
D5121 B0EAKM000122 DIODE [M]
D5122 B0EAKM000122 DIODE [M]
D5123 B0EAKM000122 DIODE [M]
D5124 B0EAKM000122 DIODE [M]
D5125 B0AACK000004 DIODE [M]
D5126 B0ACCK000005 DIODE [M]
D5128 B0EAKM000122 DIODE [M]
D5129 B0EAKM000122 DIODE [M]
D5152 B0BA01900005 DIODE [M]
D5950 B0EAMM000038 DIODE [M]
D5951 B0EAMM000038 DIODE [M]
D5952 B0EAMM000038 DIODE [M]
D5953 B0EAMM000038 DIODE [M]
D5954 B0EAKM000122 DIODE [M]
D5955 B0EAKM000122 DIODE [M]
D5956 B0EAKM000122 DIODE [M]
D5957 B0EAKM000122 DIODE [M]
D5958 B0EAKM000122 DIODE [M]
D5959 B0EAKM000122 DIODE [M]
D5960 B0BA02400030 DIODE [M]
D5961 B0AACK000004 DIODE [M]
D5962 B0AACK000004 DIODE [M]
D5963 B0AACK000004 DIODE [M]
D5964 B0BA6R800008 DIODE [M]
D5965 B0AACK000004 DIODE [M]
D5966 B0AACK000004 DIODE [M]
D5986 B0AACK000004 DIODE [M]
D5987 B0AACK000004 DIODE [M]
D6458 B3AAA0000583 DIODE [M]
D6635 B0BC5R600003 DIODE [M]
D7650 MAZ80560ML DIODE [M]
VARIABLE RESISTORS
VR6491 EVEKE2F3524B VR VOLUME JOG [M]
SWITCHES
S951 K0J1BB000017 SW MODE [M]
S952 K0J1BB000021 SW HALF [M]
S971 K0J1BB000017 SW MODE [M]
S972 K0J1BB000021 SW HALF [M]
S975 K0J1BB000021 SW RECINH_F [M]
S6101 EVQ21405RJ SW POWER [M]
S6102 EVQ21405RJ SW SINGLE DISC CHANGE [M]
S6103 EVQ21405RJ SW OPEN/CLOSE [M]
S6104 EVQ21405RJ SW CD 1 [M]
S6105 EVQ21405RJ SW CD 2 [M]
S6106 EVQ21405RJ SW CD 3 [M]
S6107 EVQ21405RJ SW CD 4 [M]
S6108 EVQ21405RJ SW CD 5 [M]
S6201 EVQ21405RJ SW DECK 2 OPEN [M]
S6202 EVQ21405RJ SW DISPLAY/DEMO [M]
S6203 EVQ21405RJ SW DECK 1/2 [M]
S6204 EVQ21405RJ SW H.BASS [M]
S6205 EVQ21405RJ SW FF [M]
S6206 EVQ21405RJ SW REW [M]
S6207 EVQ21405RJ SW DECK 1 OPEN [M]
S6301 EVQ21405RJ SW CD [M]
S6302 EVQ21405RJ SW TAPE [M]
S6303 EVQ21405RJ SW STOP [M]
S6304 EVQ21405RJ SW REC [M]
S6305 EVQ21405RJ SW TUNER/BAND [M]
S6306 EVQ21405RJ SW MUSIC PORT [M]
Ref. No. Part No. Part Name & Description Remarks
S6308 EVQ21405RJ SW MULTI DISC CHANGE [M]
S7201 RSH1A048-A SW RESET [M]
CONNECTORS
CN971 K1MN10B00104 10P FFC CONNECTOR [M]
CN1001 K1MN14B00058 14P FFC CONNECTOR [M]
CN2801 K1MN17AA0004 17P CONNECTOR [M]
CN2803 K1MN14A00049 14P FFC CONNECTOR [M]
CN2805 K1MN14A00049 14P FFC CONNECTOR [M]
CN2806 K1MN30AA0004 30P CONNECTOR [M]
CN2808 K1KB12B00036 12P CONNECTOR [M]
CN2809 K1KB12B00036 12P CONNECTOR [M]
CN2810 K1KA02AA0186 2P FAN CONNECTOR [M]
CN2951 K1MN10AA0003 10P FFC CONNECTOR [M]
CN5102 K1KA12AA0424 12P CONNECTOR [M]
CN5103 K1KA12AA0424 12P CONNECTOR [M]
CN5950 K1KA09AA0319 9P CONNECTOR [M]
CN5951 K1KA09AA0193 9P CONNECTOR [M]
CN6601 K1MN30AA0004 30P CONNECTOR [M]
CN7001 K1MN16B00154 16P CONNECTOR [M]
CN7002 K1MN17B00032 17P CONNECTOR [M]
CS1001 K1MY05AA0043 5P CONNECTOR [M]
CS1002 K1MN05A00039 5P CONNECTOR [M]
COILS & TRANSFORMERS
L1001 G0C470JA0052 RF CHOKE COIL [M]
L1002 G2ZZ00000024 BIAS OCS COIL [M]
L2601 G2A411C00001 AM COIL [M]
L2602 G2BPC0000016 OSCILLATOR COIL [M]
L2961 G0C101JA0052 INDUCTOR [M]
L2962 G0C101JA0052 INDUCTOR [M]
L5101 J0JKB0000037 FILTER [M]
L5102 J0JKB0000037 FILTER [M]
L5301 G0C220Z00002 COIL [M]
L5601 G0B9R5K00001 COIL [M]
L5602 G0B9R5K00001 COIL [M]
L5950 ELF15N035AN LINE FILTER [M]
T5950 G4CYAYY00058 TRANSFORMER [M]
T5951 RTP1H3E002 BACK-UP TRANSFORMER [M]
COMPONENT COMBINATIONS
Z971 RGSD12A1445T RADA RESISTOR [M]
Z2602 G2BAD0000003 AM IFT [M]
Z2620 ENV17290G1Y FM TUNER PACK [M]
Z5950 ERZV10V511CS ZENER [M]
Z6481 B3RAB0000025 REMOTE SENSOR [M]
CERAMIC FILTERS
CF2601 J0B1075AA006 CERAMIC CAPACITOR [M]
CF2602 J0B1075AA006 CERAMIC CAPACITOR [M]
RELAY
RL5950 K6B1AEA00015 POWER RELAY [M]
OSCILLATORS
X2602 H3F1065A0002 DIELECTRIC RESONATOR [M]
X2603 H0H720400007 CRYSTAL [M]
X2801 H0A327200115 CRYSTAL [M]
X2802 H2B100500004 CERAMIC RESONATOR [M]
X2803 H0H433400002 CRYSTAL [M]
X5201 H2A415300001 OSCILLATOR [M]
X5202 H2A375300003 OSCILLATOR [M]
X7201 H2B169500005 CRYSTAL [M]
DISPLAY TUBE
97
SA-AK240E / SA-AK240EB / SA-AK240EG
