-S601
:
Super surround switch (S.SURROUND)
-S602
:
Cinema mode switch (CINEMA)
-S603
:
Standby/on switch (POWER, /I)
-S604
:
Clock/timer switch (CLOCK/TIMER)
-S605
:
Memory switch (MEMORY)
-S606
:
Disc tray open/close switch ( ,OPEN/
CLOSE)
-S607
:
Volume control switch (VOLUME
DOWN)
-S608
:
Volume control switch (VOLUME Up)
-S609
:
Play switch ( )
-S610
:
Pause/FM mode select switch ( , FM
MODE)
-S611
:
Stop/tuning mode select switch ( ,
TUNE MODE)
-S612
:
Skip/search/tune/time adjust switch (
)
-S613
:
Skip/search/tune/time adjust switch (
)
-S614
:
Tuner/band select switch (TUNER/BAND)
-S615
:
AUX switch (AUX)
-S790
:
Disc tray open detect switch
-S791
:
Disc tray close detect switch
- Indicated voltage values are the standard values for the unit
meaured by the DC electronic circuit tester (high-impedance) with
the chassis taken as standard. / Therefore, there may exist some
error in the voltage values, depending on theinternal impedance of
the DC circuit tester. / No mark ............ CD STOP / ...............
CD playback (1kHz, L+R, 0dB)
- Important safety notice: / Components identified by mark have
special characteristics important for safety. / Furthermore, special
parts which have purposes of fire-retardent (resistors), high-quality
sound (capacitors), low-noise (resistors),etc. are used. / When
replacing any of components, be sure to use only manufacturers
specified parts shown in the parts list.
- Caution! / IC and LSI are sensitive to static electricity. / Secondary
trouble can be prevented by taking care during repair. / Ground
the soldering iron. / Put a conductive mat on the work table. / Do
