Ref. No. Part No. Part Name & Description Pcs. Remarks
CABINET AND CHASSIS
1 RGP0794A-A ORNAMENT PANEL 1 [M]
2 RKM0415A-S FRONT PANEL 1 [M]
4 RGP0793-Q LCD PANEL 1 [M]
5 RGU1883-H VOLUME BASE 1 [M]
6 RGU1871-S VOLUME BUTTON 1 [M]
7 RGU1869-S1 OPERATION BUTTON 1 [M]
8 RGU1870-S1 EJECT BUTTON 1 [M]
9 RGU1868-S1 POWER BUTTON 1 [M]
10 RGL0502-Q LED PANEL 1 [M]
11 RME0324 EARTH SPRING 1 [M]
12 RKA0059-K LEG RUBBER 4 [M]
13 RFKPAPM15EGS MOTOR ASS'Y 1 [M]
14 RDG0474 TRANSFER GEAR (A) 1 [M]
15 RDP0056 BELT PULLEY 1 [M]
16 RMG0158 BELT 1 [M]
17 RMR1293-W GEAR FIXTURE 1 [M]
18 RMK0450-1 MICON PCB CHASSIS 1 [M]
19 RDG0475 TRANSFER GEAR (B) 1 [M]
20 RMC0404 FRICTION SPRING 1 [M]
21 RGQ0261-W LAMP FRONT COVER 1 [M]
22 RDG0478 RACK (L) 1 [M]
23 RDG0479 RACK (R) 1 [M]
24 RGQ0262-W1 SHUTTER PANEL 1 [M]
25 RMR1296-W DISORDER SHEET 1 [M]
26 RMR1295-W LAMP COVER 1 [M]
27 RMS0676 GEAR SHAFT 1 [M]
28 RDG0476 GEAR 1 [M]
29 RGR0302A-C REAR PANEL 1 [M]GCS
29 RGR0302B-C REAR PANEL 1 [M]GK
30 REM0072-3 FAN 1 [M]
31 RGK1256-S DVD LID 1 [M]
32 RKQ0089-J PCB SPACER 2 [M]
33 RKM0416-S1 TOP CABINET 1 [M]
34 RMZ0339 COVER 1 [M]
35 RMN0595 LCD HOLDER 1 [M]
36 RHD30007-S SCREW 4 [M]
37 RMK0451 BOTTOM CHASSIS 1 [M]
38 RMC0430 EARTH PLATE (B) 1 [M]GK
39 RMC0429 EARTH PLATE (A) 2 [M]
40 RMN0091 PCB SPACER 1 [M]
41 RMN0337 PCB SUPPORT 1 [M]
42 RMV0207 SENSOR COVER 1 [M]
43 RMY0259 HEAT SINK (C) 1 [M]
44 XTB3+10JFZ SCREW 30 [M]
45 XTB3+20J1 SCREW 2 [M]
46 XTBS26+10J SCREW 9 [M]
47 XTBS3+8JFZ1 SCREW 17 [M]
48 XTW3+10T SCREW 4 [M]
49 XTWS3+8T SCREW 1 [M]
50 XYN2+F4 SCREW 2 [M]
51 REE0998 MICON PCB AUDIO PCB 1 [M]
32
