Ref. No. Part No. Part Name & Description Pcs. Remarks
52 REE0999 MICON PAB PANEL PCB 2 [M]
53 REE1003 DVD MODLE - AUDIO PC 1 [M]
54 REE1004 DVD MODLE - AUDIO PC 1 [M]
55 REE1001-1 DVD MODULE - DVD F.E 1 [M]
56 REE1002 DVD MODULE - DVD F.E 1 [M]
57 REX1018 TRANS TO POWER (10 P 1 [M]
58 REX1019 TRANS TO MICON 11P W 1 [M]
59 REX1020Y CR2 LOADING TO MICON 1 [M]
60 REX1021 MICON TO MOTOR 2P WI 1 [M]
61 REX1022Y TRANS TO DVD MODULE 1 [M]
62 RHD30078 SCREW 3 [M]
63 RMX0181 BE PCB SPACER 1 [M]
64 RMY0256 HEAT SINK (A) 1 [M]
65 RMY0260 HEAT SINK (SMALL) 1 [M]
66 RKW0608-Q SENSOR PANEL 1 [M]
67 RXX0223-1 COMPLETE HEAT SINK 1 [M]
68 SHR301 LEAD CLAMPER 1 [M]
TRAVERSE DECK
301 RFKJAPM08PCS MECHA CHASSIS ASS'Y 1 [M]
302 REM0019 MOTOR ASSY 1 [M]
303 RMK0255 BELT COVER 1 [M]
304 RGQ0144-K TRAY NL 1 [M]
305 VMT0994 RUBBER CUSHION 1 [M]
306 VHD1223 FLOATING SCREW 3 [M]
311 XTV2+6G PCB SCREW 1 [M]
312 RME0063 LOCK LEVER SPRING 1 [M]
313 RMM0079A-1 SLIDE PLATE 1 1 [M]
314 RML0178-1 LOCK LEVER 1 [M]
315 RDG0144 DRIVE GEAR 2 1 [M]
316 RHD20009-1 SCREW 1 [M]
317 RME0087A-1 ASSIST SPRING 1 [M]
318 RML0177 CHANGE LEVER 1 [M]
319 RMM0059A-1 SLIDE PLATE 2 1 [M]
320 RMR1302-W FIXED PLATE 1 [M]
321 RHM0001 MAGNET 1 [M]
322 RMR1301-K CLAMPER 1 [M]
323 XTN26+6G SCREW 2 [M]
324 RMA1334 CLAMPER PLATE 1 [M]
325 XYN2+F6FZ SCREW 2 [M]
326 RMG0158 BELT 1 [M]
328 RDG0142 RELAY GREAR 1 [M]
329 RDG0193 DRIVE GEAR 1 1 [M]
330 RDP0065 RELAY PULLEY 1 [M]
331 RMM0083 DRIVE RACK 1 [M]
332 RMA1003 BACK YOKE 1 [M]
334 RMC0387 SUPPORT SPRING 1 [M]
335 RMN0618 GND HOLDER 1 [M]
336 RMR1305-K TRV CHASSIS 1 [M]
337 RSC0572 GND TAPE 1 [M]
338 XTV2+5G PCB SCREW 4 [M]
339 SHR415 PLASTIC RIVET 1 [M]
401 VWJ1388 SPINDLE FFC 1
33
