Panasonic SA-PM11 - CD;Changer and Power Supply Errors

No. Error Error
Display
Problem condition
1 MODE SW
detection error
H01 Faulty operation of cassette mechanism.
Faulty contact or short-circuit of mechanism
mode
switch (S951, S971).
2 REC INH SW
detection error
H02 Recording not possible.
Faulty contact or short-circuit of REC INH
switch
S975).
3 HALF SW
detection error
H03 Playback cannot perform.
Faulty contact or short-circuit of HALF siwtch (
S952,
S972).
4 Reel Pulse
detection error
F01 The tape advances slightly and then stops.
Faulty reel pulse, faulty hole detect IC (IC951,
IC971).
5 TPS abnormal F02 Cassette deck will not perform TPS function.
Faulty playback EQ/recording amplifier IC (
IC101).
10.2. Error detection for CD/Changer block
No. Error Error
Display
Problem condition
1 REST SW detection error F15 CD does not function.
This error occurs when the Optical Pick Up
REST
(S701) is not
detected within the specified time (about 8
seconds)
2 CD tray opens automatically F16 CLAMP switch (S4) NG (Check & Replace)
3 Does not startup when
[PLAY]
button is pressed
F17 BOTTOM switch (S5) NG (Check & Replace)
4 Transmission error between
CD
servo LSI and micon
F26 CD does not function.
This error occurs when the POWER is ON for
the
block and an error is
detected after the transmission has started.
5 Startup fails even when you
insert CD or the selected
disc tray
does not open
F27 Tray 1 detect switch or Tray 2 detect switch NG
(
& Replace)
6 Cannot insert CD F28 Tray 1 detect switch NG (Check & Replace)
7 Cannot eject CD F29 Check if disc is stuck. Tray 2 detect switch NG
(Confirm & Replace)
8 The CD tray closes H15 CD disc tray detect switch NG (S3) (Check &
Replace)
10.3. Power Supply related error detection
