Panasonic SA-PT470EB - Page 89

89
11.1.9. D-Amp P.C.B. (IC5000 ~ IC5501)
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 0 -29.3 -19.2 -29.3 -0.1 8.9 29.3 -29.0 -29.0 0 29.0
STANDBY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 0.1 -29.3 -19.2 -29.3 -0.1 8.9 29.3 -29.0 -29.0 0 29.0
REF NO.
MODE 21 22 23
CD PLAY 0 0 2.5
STANDBY 0 0 2.5
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 0 -29.3 -19.2 -29.3 -0.1 8.9 29.3 -29.0 -29.0 0 29.0
STANDBY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 0 -29.3 -19.2 -29.3 -0.1 8.9 29.3 -29.0 -29.0 0 29.0
REF NO.
MODE 21 22 23
CD PLAY 0 0 2.6
STANDBY 0 0 2.6
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 0 -29.3 -19.2 -29.3 -0.1 8.9 29.3 -29.0 -29.0 0 29.0
STANDBY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 0 -29.3 -19.2 -29.3 -0.1 8.9 29.3 -29.0 -29.0 0 29.0
REF NO.
MODE 21 22 23
CD PLAY 0 0 2.5
STANDBY 0 0 2.5
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 8.9 -0.1 -29.3 -19.2 -29.3 -0.1 9.0 29.3 -29.0 -29.0 0 29.0
STANDBY 2.5 0 0 29.0 0 -29.0 -20.6 29.3 9.0 -0.1 -29.3 -19.2 -29.3 -0.1 9.0 29.3 -29.0 -29.0 0 29.0
REF NO.
MODE 21 22 23
CD PLAY 0 0 2.6
STANDBY 0 0 2.6
REF NO.
MODE 1234567891011121314
CD PLAY 0 5.2 4.9 0 2.7 2.2 0 2.5 2.6 2.6 2.5 2.5 2.6 5.2
STANDBY 0 5.2 4.9 0 2.7 2.2 0 2.5 2.6 2.6 2.5 2.5 2.6 5.2
REF NO.
MODE 1234567891011121314
CD PLAY 2.5 2.6 2.5 0 2.6 0 0 0 0 0 0 0 5.2 5.2
STANDBY 2.5 2.6 2.5 0 2.6 0 0 0 0 0 0 0 5.2 5.2
IC5300
IC5300
IC5000
IC5000
IC5200
IC5200
IC5400
IC5400
IC5501
SA-PT470EB/EF/EG D-AMP P.C.B.
IC5500
