11.1.10. D-Amp P.C.B. (Q5101 ~ Q5644)
11.1.11. Auto Setup Speaker P.C.B.
11.1.12. Scart P.C.B.
REF NO. Q5601 Q5602
MODE ECB ECB ECB ECB ECB
CD PLAY 0 5.2 0 0 5.1 0 0 0 0.7 0 0.1 0.6 5.2 5.2 4.5
STANDBY 0 5.2 0 0 5.2 0 0 0 0.7 0 0.1 0.7 5.2 5.2 4.5
REF NO.
MODE ECB ECB ECB ECB ECB
CD PLAY 0 0 0.7 7.2 17.1 7.7 0 5.2 0 0 0.1 0.7 0 3.9 0.4
STANDBY 0 0 0.7 7.2 17.1 7.7 0 5.2 0 0 0.1 0.7 0 3.9 0.3
Q5102 Q5603Q5101
SA-PT470EB/EF/EG D-AMP P.C.B.
Q5640 Q5641 Q5642 Q5644Q5604
REF NO.
MODE 12345678
CD PLAY 0 0 0 -6.8 0 0 0 6.9
STANDBY 0 0 0 -6.8 0 0 0 6.9
REF NO.
MODE E C B E C B E C B E C B
CD PLAY 0 0 -4.6 3.6 3.6 3.0 0 -4.6 0 0.6 0 0
STANDBY 0 0 -4.6 3.6 3.6 3.0 0 -4.6 0 0.6 0 0
IC6531
SA-PT470EB/EF/EG AUTO SETUP SPEAKER P.C.B.
Q6531 Q6532 Q6533
Q6534
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 5.2 0 0 2.0 4.8 0 0 1.8 2.1 5.2 0 0 0 0 0 5.2 3.3 3.3 0 3.3
STANDBY 5.2 0 0 2.0 4.8 0 0 1.8 2.1 5.2 0 0 0 0 0 5.2 3.3 3.3 0 3.3
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32
CD PLAY 3.3 0 3.3 3.3 0 1.4 1.4 0 1.4 1.4 0 2.0
STANDBY 3.4 0 3.4 3.4 0 1.4 1.4 0 1.4 1.4 0 2.0
REF NO.
MODE 1234567891011121314
CD PLAY 0 5.6 0 5.6 0 11.2 0 5.6 5.6 5.6 5.6 11.2 0 11.2
STANDBY 0 5.6 0 5.6 0 11.2 0 5.6 5.6 5.6 5.6 11.2 0 11.2
REF NO.
MODE ECB ECB ECB ECB ECB
CD PLAY 0 4.8 0 0 5.2 0 11.2 16.9 11.8 5.2 0 5.2 0 11.2 0.1
STANDBY 0 4.8 0 0 5.2 0 11.2 17.0 11.8 5.2 0 5.2 0 11.2 0.1
REF NO.
MODE ECB ECB ECB ECB ECB
CD PLAY 1.1 0 1.1 0 11.2 0 0 0 5.0 0 11.2 -1.7 0 0 -1.7
STANDBY 1.1 0 1.1 0 11.2 0 0 0 5.0 0 11.2 0.2 0 0 0.2
REF NO.
MODE E C B
CD PLAY 0 0 -1.7
STANDBY 0 0 0.2
IC4101
Q4001
SA-PT470EB/EF/EG SCART P.C.B.
Q4012
IC4101
IC4104
Q4008 Q4009
Q4010
Q4011
Q4002 Q4003
Q4004
Q4005
Q4007
