4 Replacement Parts List
Notes:
•
• •
• The below Component Parts List applies to models including SA-VK750EE/GCP-S, SA-VK850EE/GCP-S, SA-VK950EE/GCP-
S.
•
• •
• Important safety notice:
Components identified by
mark have special characteristics important for safety purpose.
Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low-noise
(resistors), etc. are used.
When replacing any of components, be sure to use only manufacture’s specified parts shown in the parts list.
•
• •
• Warning: This product uses a laser diode. Refer to caution statements.
•
• •
• Capacity values are in microfarads (µF) unless specified otherwise, P=Pico-farads (pF), F=Farads (F).
•
• •
• Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000K (OHM).
•
• •
• The parenthesized indications in the Remarks columns specify the model names and areas. (Refer to the cover page)
•
• •
• The marking (RTL) indicates the retention time is limited for this item. After the discontinuation of this assembly in production,
it will no longer be available.
•
• •
• Parts mentioned [M] are supplied from PAVCSG.
•
• •
• Parts mentioned [SPG] are supplied from PAVC.
•
• •
• Reference for O/I book languages are as follows:
Ar: Arablic Du: Dutch It: Italian Sp: Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn Simplified Chinese
Pe: Persian Ur: Ukrainian Pr: Portuguese
9
SA-VK750EE / SA-VK750GCP / SA-VK850EE / SA-VK850GCP / SA-VK950EE / SA-VK950GCP
