Specifications
AMPLIFIER SECTION
RMS output power (non-simultaneous drive)
Front ch (L, R ch)
70 W per channel (1 kHz, 10 %, 6 ≠)
Centre ch (C ch)
70 W per channel (1 kHz, 10 %, 6 ≠)
Subwoofer ch
140 W per channel (100 Hz, 10 %, 3 ≠)
Total RMS output power
350 W
TERMINAL SECTION
HDAVI Control
This unit supports “HDAVI Control 5” function.
HDMI AV input (BD/DVD)
1
Input connector
Type A (19 pin)
HDMI AV output (TV (ARC))
1
Output connector
Type A (19 pin)
Digital audio input (TV)
Optical digital input
Optical terminal
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format
LPCM, Dolby Digital, DTS Digital Surround
TM
IR Blaster
Terminal Type
3.5 mm jack
USB Port
For service use only.
LAN Port
10 Base-T /100 Base-TX
SPEAKER SECTION
Front speakers (Built-in, L/R/C)
Full range
6.5 cm cone type k1/ch
Active subwoofer
Woofer
16 cm cone type k1
GENERAL
Power consumption
Main unit
42 W
Active subwoofer
30 W
In standby condition
Main unit
When “Network Standby”
§1
is “OFF”
Approx. 0.48 W
When “Network Standby”
§1
is “ON”
Approx. 4.3 W
Active subwoofer
Power switch off
Approx. 0.48 W
The wireless link is not activated
Approx. 1.0 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
Main unit
For table top layout
950 mmk55 mmk120 mm
For wall mounting layout
950 mmk125.5 mmk57.2 mm
Active subwoofer
180 mmk378 mmk303 mm
Mass
Main unit
For table top layout
Approx. 2.5 kg
For wall mounting layout
Approx. 2.5 kg
Active subwoofer
Approx. 4.7 kg
Operating temperature range
0
o
C to i40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
SC-ALL70T-SQT0935.book 42 ページ ２０１５年４月２８日 火曜日 午前１０時５分

Panasonic SC-ALL70T Specifications

General

Audio decoders	Dolby Digital, Dolby Pro Logic II, DTS Digital Surround
RMS rated power	350 W
Audio output channels	3.1 channels
Audio Return Channel (ARC)	Yes
Impedance	6 Ω
Woofer diameter	160 mm
Soundbar speaker RMS power	70 W
Total Harmonic Distortion (THD)	10 %
Subwoofer connectivity	Wireless
Receiver included	-
Product color	Black
HDMI in	1
Connectivity technology	Wired & Wireless
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.48 W
Power consumption (typical)	42 W

Weight and Dimensions

Depth	120 mm
Width	950 mm
Height	55 mm
Soundbar weight	2600 g
Subwoofer depth	303 mm
Subwoofer width	180 mm
Subwoofer height	378 mm
Subwoofer weight	5000 g
