6
RQT9445
Control reference guide (main unit)
1
Standby/on switch (
Í
/I
)
(
>
14)
Press to switch the unit from on to standby mode or vice versa. In
standby mode, the unit is still consuming a small amount of
power.
2
Open or close the disc tray (
>
18)
3
SMART SETUP
button
(
>
14)
4
Stop (
>
19)
5
Start play (
>
18)
6
Disc tray (
>
18)
7
Connect
iPod (>
30)
8
SD card slot (
>
18)
9 Connect Auto speaker setup microphone (> 14)
:
The indicator lights when there is surround sound effect. (
>
17)
;
USB port (
>
18)
<
Display
=
Select the source (
>
16)
BD/DVD
)
SD
)
IPOD
)
FM
)
USB
)
AUX
)
D-IN 1
)
D-IN 2
“SD” and “USB” on the unit’s display is not displayed when
the SD card or USB is not in the SD card slot or USB port.
>
Skip or slow-search play (
>
19)/Select the radio stations
(
>
26)
?
Volume indicator
It is possible to set the indicator to turn on/off.
(>
38, “FL
Display”)
@
Adjust the volume of the main unit (
>
18)
≥
When pulled hard, the volume knob may come off.
≥
To prevent children from swallowing the volume knob, do
not pull off the volume knob.
A
Connect headphones (not included)
(
>
18)
B
Remote control signal sensor
1
AC IN terminal (
>
13)
2 Cooling fan
3 SPEAKERS terminal (> 9)
4 AUX (TV) terminal (> 10, 11)
This terminal can also be used for equipment other than the
TV.
5 COMPONENT VIDEO OUT terminal (> 11)
6 OPTICAL DIGITAL IN terminals
Terminal 1(TV) is designated for connection with the TV.
(> 10, 11)
Terminal 2(STB) can be used for connection with devices
other than the STB. (> 12)
7 FM Radio antenna terminal (> 12)
8 Digital transmitter dock (> 42)
9 LAN port (> 13)
: HDMI AV OUT terminal (> 11)
;
VIDEO OUT terminal (
>
10)
Front panel
SMART SETUP
Dock for iPod
OPEN CLOSE
VOLUME
SURROUND OUTPUT
TUNE
SELECTOR
SETUP MIC
SD CARD
Dock for iPod
1
76
13
2
3 4 5
8 119 10 1412
16
15
1817
Pull open.
Rear panel terminals
SPEAKERS
CENTER
3
Ω
3
Ω
FRONT
3
Ω
SURROUND
5
2
1
4
3
R
L
R
L
TRANSMITTER
DIGITAL
AV O UT
COMPONENT
VIDEO OUT
VIDEO
OUT
Y
P
R
PB
OPTICAL
2(STB) 1(TV)
DIGITAL IN
+
-
FM ANT
75Ω
L
R
AUX(TV)
AC IN
WOOFER
6
3
Ω
SUB-
1
2
3 4 5
9 10 11
76
8
Getting started
