Attach the stand to the unit
Support stand
(included)
Rear of the main unit
Ensure the stand is securely attached to the main unit
for stabilization.
Insert the stand fully until
a click is heard.
The supplied stand is specially designed for use
with this unit.
Only use as indicated in this setup.
•
•
Note
Please check and identify the supplied
accessories.
Use numbers indicated in parentheses when asking for
replacement parts.
(Product numbers correct as of February 2008. These may
be subject to change.)
To order accessories, call the dealer from whom you have
made your purchase.
(N2QAYB000269)
(RFAX0023)
(N1DADYY00003)
The included AC power supply cord is for use with this unit only.
Do not use it with other equipment.
Do not use an AC power supply cord from other equipment.
•
•
Note
(RYQX0512-H)
The remote control
R6/LR6, AA
g Batteries
Insert so the poles (+ and – ) match
those in the remote control.
Do not use rechargeable type batteries.
Do not heat or expose to flame.
Do not leave the battery(ies) in an
automobile exposed to direct sunlight
for a long period of time with doors and
windows closed.
•
•
•
•
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
g Use
Aim at the sensor, avoiding
obstacles, at a maximum range
of 7 m (23 feet) directly in front
of the unit.
Operation can be affected by
strong light sources, such as
direct sunlight, and the glass
doors on cabinets.
•
•
Remote control signal sensor
1 Remote control
1 FM/AM antenna
1 Support stand
1 M3 audio cable
1 AC power supply cord
2 Batteries
(K2KC39A00002)
IMPORTANT SAFETY INSTRUCTIONS 2
Supplied accessories 3
The remote control 3
Attach the stand to the unit 3
Control guide 4
Placement of speakers 4
Connections 5
Disc operations 5
Radio operations 7
Sound adjustment 7
Timer 8
Changing the main unit and
remote control mode 8
Troubleshooting guide 9
Maintenance 9
Specifications 10
Listening caution 10
Product Service 10
Limited Warranty 11
Supplied accessories
Table of contents
