Panasonic SC-HTB510 User Manual

5
TQBJ2196
Overview of controls
This system (Front)
A Standby/on switch [1]
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
B Adjust the volume level (~17)
C Select the input source
D Select the Bluetooth
®
device as the source
To start Bluetooth
®
pairing, press and hold
[ -PAIRING].
E Remote control sensor
Point the remote control at the remote control
sensor, away from obstacles and within the
operation range.
Distance: Within approximately 7 m
Angle: Approximately 20° up and down, 30° left
and right
F Sound modes indicators
Switch on when the corresponding sound mode
is selected.
 STANDARD indicator
 MUSIC indicator
 CINEMA indicator
 NEWS indicator
 VOICE indicator
G Selector indicators
 HDMI (ARC) indicator
 OPTICAL indicator
 NET indicator
 (Bluetooth
®
) indicator
H WIRELESS LINK indicator (~16)
Main unit
Active subwoofer
HDMI (ARC) NET OPTICAL
TQBJ2196_en.fm Page 5 Tuesday, February 26, 2019 6:32 PM

Panasonic SC-HTB510 Specifications

General

Audio decoders	DTS Digital Surround, Dolby Digital
RMS rated power	240 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Wi-Fi	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial in	0
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	2 W
Product color	Black
Handheld remote control	-
Apple docking compatibility	Not supported
Woofer diameter (subwoofer)	6.3 \
Number of full-range drivers	2

Weight and Dimensions

Width	- mm
Soundbar weight	- g
