Control reference guide
1 Standby/on switch (Í/I)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
2 Adjust the volume of this system
3 Select the input source
“TV” !# “BD/DVD”
4 Input selector indicators (> 17)
A TV indicator
Lights green when the TV is the audio
source
B BD/DVD indicator
Lights amber when the device connected to
the HDMI IN terminal is the audio source
5 Remote control signal sensor (> 7)
6 Audio format indicators* (> 17)
C Dolby
®
Digital indicator
Lights when Dolby Digital is the current
audio format
D DTS indicator
Lights when DTS is the current audio
format
E PCM indicator
Lights when PCM (2ch, Multi-channel) is
the current audio format
7 WIRELESS LINK indicator (> 16)
1 AC IN terminal (> 16)
2 Digital transmitter dock (> 15)
3 OPTICAL DIGITAL AUDIO IN terminal (> 14)
4 HDMI OUT terminal (ARC compatible) (> 14)
5 HDMI IN terminal (> 15)
6 Active subwoofer on/off button
* The indicators will also blink in various conditions. (> 22)
This system (Front)
1
46
5
7
23
Main unit Active subwoofer
This system (Rear)
DIGITAL TRANSMITTER
1
6
3
4
5
1
2
