16
6.3. Remote Control Key Button Operations
1 Turn the main unit on or off
2 Adjust the dialog effect level
3 Adjust the output level of the active subwoofer
(bass sound)
4 Adjust the volume of this system
5 Mute the sound
6 Select the TV as the source
7 Select the BD/DVD as the source
8 Select the AUX as the source
“AUX1” “AUX2”
DIALOG LEVEL
BD/DVD
1
6
7
2
3
4
5
8
AUX
Remove the insulation sheet before using.
To replace a button-type battery
While pressing the stopper , pull out the
battery holder.
Set the button-type battery with its ( + ) mark
facing upward and then put the battery
holder back in place.
When replacing the battery, use:
CR2025 (Lithium battery)
Keep the button-type battery out of reach of
children to prevent swallowing.
A
B
1
2
To Next Page
