Panasonic SC-HTB550GK

97
16 Schematic Diagram
16.1. Schematic Diagram Notes
(All schematic diagrams may be modified at any time with
the development of new technology)
Notes:
Main Unit (SU-HTB550)
Active Subwoofer (SB-HWA520)
• Important safety notice:
Components identified by mark have special characteris-
tics important for safety.
Furthermore, special parts which have purposes of fire-retar-
dant (resistors), high quality sound (capacitors), low-noise
(resistors), etc are used.
When replacing any of components, be sure to use only
manufacturer’s specified parts shown in the parts list.
• In case of AC rated voltage Capacitors, the part no. and val-
ues will be indicated in the Schematic Diagram.
AC rated voltage capacitors:
C5700, C5701, C5702, C5703, C5705
• Resistor
Unit of resistance is OHM [Ω] (K=1,000, M=1,000,000).
• Capacitor
Unit of capacitance is μF, unless otherwise noted. F=Farads,
pF=pico-Farad.
• Coil
Unit of inductance is H, unless otherwise noted.
•
*
REF IS FOR INDICATION ONLY.
• Voltage and signal line
S6001: POWER switch.
S6002: VOLUME DOWN switch.
S6003: VOLUME UP switch.
S6004: SELECTOR switch.
S1000: I/D SET switch.
S1001: POWER switch.
: +B Signal Line
: -B Signal Line
: HDMI/Optical/Bluetooth/Aux Audio Input
Signal Line
: HDMI Video Input Signal Line
: Audio Output Signal Line
: HDMI Video Output Signal Line
