Note on AC mains lead
(For the AC mains plug of three pins)
How to replace the fuse
The location of the fuse differ according to the type of AC
mains plug (figures A and B). Confirm the AC mains plug
fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
Supplied accessories
Check and identify the supplied accessories.
Note:
Please use the supplied AC mains lead suitable for the
household mains socket.
In Saudi Arabia and Singapore, please use the moulded
three pin mains plug.
Placement of speakers
1 Subwoofer SB-MAW370 (L)
2 Subwoofer SB-MAW370 (R)
3 Subwoofer SB-MAY370 (L)
4 Subwoofer SB-MAY370 (R)
5 Front speaker SB-MAF370 (L)
6 Front speaker SB-MAF370 (R)
7 Stacking bracket
Setup 1
Setup 2
Subwoofers
Put on the floor or a sturdy shelf to reduce vibration.
Figure A Figure B
Fuse cover
Figure A Figure B
Fuse (5 ampere)
Fuse (5 ampere)
 4 x AC mains lead
(For Saudi Arabia, Singapore and areas that
use the moulded three pin mains plug)
(For Thailand)
 1 x AM loop antenna
 1 x FM indoor antenna
 1 x Remote control battery
 1 x Remote control
(N2QAYB000915)
 4 x Stacking bracket
(In speakers packaging)
CAUTION!
Do not touch the subwoofer cones reverberating
surfaces:
• This may damage the subwoofer cone.
• The subwoofer cone may be hot.

 

 




