Specifications
█
General
Dimensions (W x H x D)
SA-PM272/SA-PM270 184 mm × 123 mm × 231 mm
SB-PM02 139 mm × 224 mm × 136 mm
Mass
SA-PM272/SA-PM270 1.1 kg
SB-PM02 1.3 kg
Operating temperature range 0 °C to +40 °C
Operating humidity range 35% to 80% RH (no condensation)
█
Amplifier section
RMS output power
Front Ch (both ch driven) 10 W per channel (6 Ω), 1 kHz, 10% THD
Total RMS power 20 W
█
Disc section
Disc played (8 cm or 12 cm) CD, CD-R/RW
Pick up
Wavelength 790 nm (CD)
NORSK
Bølgelengde 790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
Format CD-DA, MP3
*
1
*
1
MPEG-1 Layer 3, MPEG-2 Layer 3
█
Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range 87.50 MHz to 108.00 MHz (50 kHz step)
█
DAB+ section
[PM272]
DAB memories 20 channels
Frequency band (wavelength)
Band III (All region) 5A to 13F (174.928 MHz to 239.200 MHz)
Sensitivity *BER 4x10
-4
Min requirement –98 dBm
DAB external antenna terminal F - Connector (75 Ω)
Power supply AC 220 V to 240 V, 50 Hz
Power consumption 14 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.2 W
With “BLUETOOTH STANDBY” set to “ON” 0.3 W
