Panasonic SC-PT170 - Specifications; SPEAKER SECTION; GENERAL

37
RQTX0246
Getting StartedPlaying DiscsOther OperationsReference
§8
Rating with Low-cut filter equipped Amplifier
[Note]
1 Specifications are subject to change without notice.
Mass and dimensions are approximate.
2 Total harmonic distortion is measured by a digital
spectrum analyzer.
SPEAKER SECTION
[PT170] [Front\speakers\SB-HF170]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Full range 6.5 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W
§ 8
(Max)
80 dB/W (1.0 m)
96 Hz to 25 kHz (
j 16 dB)
120 Hz to 22 kHz (
j 10 dB)
92 mm
k 128 mm k 81 mm
0.47 k
g
[PT170] [Surround\speakers\SB-HS170]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Full range 6.5 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W
§ 8
(Max)
80 dB/W (1.0 m)
96 Hz to 25 kHz (
j 16 dB)
120 Hz to 22 kHz (
j 10 dB)
92 mm
k 128 mm k 81 mm
0.47 k
g
[PT170] [Center\speaker\SB-HC170]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Full range 6.5 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W
§ 8
(Max)
80 dB/W (1.0 m)
91 Hz to 25 kHz (
j 16 dB)
120 Hz to 22 kHz (
j 10 dB)
125 mm
k 94.5 mm k 81 mm
0.7 k
g
[PT175] [Front\speakers\SB-HF175]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Full range 6.5 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W
§ 8
(Max)
80 dB/W (1.0 m)
82 Hz to 25 kHz (
j 16 dB)
90 Hz to 22 kHz (
j 10 dB)
252 mm
k 1123 mm k 235 mm
3.7 k
g
[PT175] [Surround\speakers\SB-HS175]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Full range 6.5 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W
§ 8
(Max)
80 dB/W (1.0 m)
96 Hz to 25 kHz (
j 16 dB)
120 Hz to 22 kHz (
j 10 dB)
92 mm
k 142 mm k 95 mm
0.6 k
g
[PT175] [Center\speaker\SB-HC175]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Full range 6.5 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W
§ 8
(Max)
80 dB/W (1.0 m)
91 Hz to 25 kHz (
j 16 dB)
120 Hz to 22 kHz (
j 10 dB)
140 mm
k 94 mm k 95 mm
0.7 k
g
[Subwoofer\SB-HW170]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5
≠
Woofer 12 cm Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
t H t D)
Mass
55 W (Max)
80 dB/W (1.0 m)
30 Hz to 350 Hz (
j 16 dB)
39 Hz to 290 Hz (
j 10 dB)
136 mm
k 339 mm k 213 mm
2.8 k
g
GENERAL
Power supply
Power consumption
Dimensions (W
t H t D)
Mass
Operating temperature range
Operating humidity range
AC 220 V to 240 V, 50 Hz
This unit 85 W
430 mm
k 63 mm k 325 mm
This unit 3.14 k
g
0 o C to r 40 o C
35 % to 80 % RH (no condensation)
Power consumption in standby mode
approx. 0.2 W
