Ref.
No.
Part No. Part Name & Description Remarks
1 ADA39E142-0S Dispenser cover Ass´y Caution
label &
Seal
rubber
set
2 ADY02E142-W Caution label
3 ADA37E142-H Dispenser Ass´y Dispens
er
plate
set
4 ADJ15A107 Hinge screw
5 ADA08E142-W Top lid Ass´y No.6-14
set
6 ADD01E142-W Top lid
7 ADD38E142 Magnet
8 ADD36E142 Magnet plate A
9 ADJ30E142 Washer A
10 ADD22E142 Lid lever
11 ADG02E142 Spring B
12 ADD29E142-H Lid cover
13 ADD05E142-H Steam vent
14 ADD02E142 Inner lid
15 ADA04A105 Kneading blade B Unit
16 ADA12R132 Bread pan Ass´y No.17-
22 set
17 ADA12R132-0S Bread pan Bread
pan
handle
set
18 ADA29A115-0S Mounting shaft Ass´y No.19-
22 set
19 ASD191U103-K Packing
20 AMX28H-L50 Motor washer A
21 AMX13B-451 Wave washer
22 ASD863-102-W Connector upper
23 ADA25-137 Heater case base Ass´y No.20,2
4,25
set
24 ADE97A107 Connector lower Unit
25 ADE98A137 Heater case base Unit
26 ADA07E142-WS Control panel Ass´y Panel
sheet
set
27 ADA21G142-0Z Solenoid Ass´y
28 ASD850-108-W Spring A
29 ASD525-108-W Solenoid holder plate
30 ADR10E142-0S P.C.Board AB Ass´y
GER,ENG
, Flat
cable
set
31 ADP10E142 Flat cable
32 ADT03E142 P.C.B.cover
33 ADE09A107 Heater bobbin A
34 ADA22R117 Heater (Yellow Insulator)
AUST,EN
G
AC240V
550W
35 ASD452-108-K Heater bobbin B
36 ADA16A115-0S Heater case Ass´y
37 ADA11E142 Sensor Ass´y
Thermal
fuse
Unit
set
38 ADA19E142-WS Body Ass´y Rating
plate
set
39 ADY01E142 Rating plate
40 ADP11E142 Lead wire A Unit
41 ADP97A107 Lead wire B Unit
42 ADA30R107 Ground wire A Ass´y
Ground
plate
set
43 ADB10E142 P.C.B.holder
Ref.
No.
Part No. Part Name & Description Remarks
44 ADE01R117-0S Angle Unit Water
protect
ion
tape
set
45 ADA24E142 Power cord Ass´y AC
23-240V
GS3P
46 ADF05R140 Pulley B
47 ASD867-100-W Lock washer
48 ADJ16A107 Lock nut
49 ADA10R140 Motor Ass´s AC
240V
Pulley
Aset
50 ADF01R140 Belt
51 ADB02A115 Bottom plate
52 ADA28A107 Rubber foot Screw &
Spring
washer
set
53 ASD911U112BK Measuring spoon
54 ADD14A103 Measuring cup
55 ADY09E142-X Seal A ENG
Exclusi
ve use
A ADJ01A115 Screw A
B XTT4+10BFC Screw
C XTT4+18HFN Screw
D XTT4+20F Screw
E XTB4+14B Screw
F ADJ06A121 Screw F
G XTT4+8FFN-S Screw
H ASD881-100BZ Screw H
I ASD934U103 Screw W/ lock
glue
Use for
repair
J XTN4+10F Screw
K XWA4B Spring washer
L XUB8Y C-cripe
M XUE6FT U-cripe
N ADJ17A115 Screw P
O ASD938-101-D Screw R
ADZ01E142 Carton
ADZ47E142 CushionAss´y
ASD749-100 Lid protection sheet
ADZ06A115 Protection board
ADZ50E142 Operating lnstructions
ADZ63E142 Operating lnstructions C
ASR783J452AX Guarantee
5.2. Replacement Parts List (ENG)
24
SD-253
